Help CenterXYC-200 Vehicle-mounted Mobile Hydraulic Rotary Water Well Drilling Rig In Stock
Related Products
-
China Factory Direct Supplied XY-180 Hydraulic Deep Water Well Drilling RigUS$ 4000 - 6000MOQ: 1 Set -
XY-200 Maximum Borehole Depth 200m Core Drilling Rig/bore Well Drilling Machine Price in IndiaUS$ 6000 - 7500MOQ: 1 Set
-
China Supplier XY-3 600 Meters Diamond Core Machine Water Well Drilling RigUS$ 6000 - 7500MOQ: 1 Set
-
XYC-3 Truck Mounted Hydraulic Core Drilling Rig Car Rig, Car RigUS$ 4000 - 6000MOQ: 1 Set
-
XYX-130 Wheel Hydraulic Core Drilling Machine Wheel Core Drilling RigUS$ 4000 - 6000MOQ: 1 Set
Keywords: Truck mounted Rotary drilling rig, vehicle-mounted type mobile drilling rig, full hydraulic core drilling rig
1. Characteristics of XYC-200 vehicle-mounted drilling rig
l XYC-200 is a multi-function hydraulic vehicle-mounted rotary drilling rig.
l the Tang Jun automobile chassis chassis, transmission system and rig winch, mud pump and other important accessories installed in the chassis. the layout is reasonable, compact, and easy to operate.
l It is equipped with high pressure,big flow BW160mudpump,which can ensure drilling depth and diameter.
l the rig has shifting device, it can move on the vehicle and is convenient to operate while drilling.
l the hydraulic folding mast is safe and convenient to transport
2.Applications of XYC-200 drilling rig
l road and high-rise building foundation exploration
l all kinds of concrete structure inspection holes
l river embankments
l subgrade grouting holes
l drilling and direct grouting
l civil water well
l ground temperature central air conditioners.
3. Parameters of XYC-200 vehicular drilling rig
XYC-200 vehicular drilling rig | |||
Drilling depth(m) |
30-200 |
||
Drilling diameter(mm) |
300-75 |
||
Drilling Angel(mm) |
90-75 |
||
Spindle rotating speed(r/min) |
64/128/287/557 |
||
Spindle stroke(mm) |
450 |
||
|
Main hoisting capacity (single line)(Kg) |
1600 |
||
|
Main hoisting line capacity (m) |
35 |
||
Hoisting speed(r/s) |
17/35/75/151 |
||
Wireline diameter(mm) |
12.5 |
||
Mast height(mm) |
7000 |
||
Mast effective height(mm) |
6500 |
||
Kelly/active pipe(mm) |
59*53 |
||
Drill rod(mm) |
42/50/60 |
||
Drill rig weight(kg) |
1150 |
||
Power Unit |
Model |
ZS1115 diesel engine |
|
Rated power |
14.7kw/2200rpm |
||
|
BW-160 mud pump |
Rated flow(l/min) |
160 |
|
Rated pressure(mpa) |
1.3 |
||
Driving power(kw) |
5.15 |
||
|
Main machine weight (kg) |
190 |
||
Dimension(mm) |
1110*725*965 |
||
|
Chassis
|
Model |
95hp light truck The 3.3 meter steeplechase double light card |
|
Drive mode |
4*2 |
||
|
Power unit |
Model |
Quanchai 4B2-95C40 |
|
Emission standard |
GB3847-2005,GB17691-2005Ⅳ |
||
Rated power(kw) |
70 |
||
Rotating speed(r/min) |
3200 |
||
