FY400 Crawler Type Pneumatic Deep Water Drilling Machine for Sale
US$ 4000 - 6000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Master Machinery
Place of Origin:
China
Model Number:
FY-400
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
FY600 Crawler Pneumatic Water Well Drilling RigUS$ 4000 - 6000MOQ: 1 Set -
KY-200 Full Hydraulic Drilling Rig For Metal Mine ExplorationUS$ 4000 - 6000MOQ: 1 Set
-
KY-250mine Drilling Rig, Tunnel Prospecting Drilling Rig, Mine Core Drilling RigUS$ 4000 - 5500MOQ: 1 Set
-
China High Quality BXZ-2 Double Knapsack Core Drilling Rig for SaleUS$ 4000 - 6000MOQ: 1 Set
-
BXZ-1 Portable Backpack Core Drilling Rig Operated By One PearsonUS$ 4500 - 5000MOQ: 1 Set
Brand Name
Master Machinery
Place of Origin
China
Model Number
FY-400
Type
Rotary Drilling Rig
Certification
ISO-9001
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
Six Months
Power Type
Diesel
Usage
Water Well
Condition
New
Power(W)
Diesel
1.The range of application of FY400 crawler type gas drilling rig
Applicable to civil engineering drilling, geothermal drilling, drilling with large diameter and deep drilling footage, fast, flexible and efficient.
2.The technical parameter of FY400 crawler type gas drilling rig
model |
FY400 |
|
Gross weight |
T |
8.7 |
Dimension |
mm |
5050*2100*2800 |
Aperture |
mm |
140-325 |
Drilling depth |
m |
400 |
Feed stroke |
mm |
6000 |
Travel speed |
km/h |
2.5 |
Grade ability |
Max. |
30° |
Rising height from ground |
mm |
250 |
Wind pressure |
Mpa |
1.7-3.5 |
Air consumption |
m³/min |
17-35 |
Engine power |
kw |
95 |
Rotary speed |
rpm |
45-75 |
Rotation torque |
N.m |
8500-10000 |
