China Supplier XY-3 600 Meters Diamond Core Machine Water Well Drilling Rig
- Qingdao
- T/T L/C
- 7 days
You May Like
-
XYC-3 truck mounted hydraulic core drilling rig Car rig, car rig
-
XYX-130 wheel hydraulic core drilling machine Wheel core drilling rig
-
XYX-200 wheel hydraulic core drilling machine Wheel geological drilling rig
-
Sell high quality xy-150 hydraulic diamond exploration core drilling rig
-
XYD-3hydraulic core drilling machine/track hydraulic core drilling machine
-
Strong Recommend Full Hydraulic XYC-3 Vehicle-mounted Coring Drilling Rig
Product Details
| Brand Name | HuaxiaMaster | Place of Origin | China | |
| Model Number | XY-200 | Type | Rotary Drilling Rig | |
| Certification | ISO-9001 | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | Six Months | Weight | 1800 KG | |
| Dimension(L*W*H) | 2500*900*1800mm | Power Type | Diesel | |
| Voltage | 380 V | Usage | Water Well | |
| Condition | New | Power(W) | 22 KW |
Product Description
Keywords: hydraulic press drilling machine , water borehole drilling machine, drilling rig water well
1. The features of XY-3 bore well drilling machine
l XY-3 water well drilling machine adopts CG140 model auto transmission, with 10 rotation speed series and reasonable speed range, with eight forward rotation gears and two reverse rotation gears, it’s high speed, strong stroke and wide scope of application.
l With large torque, strong bearing capacity, it can realize long distance control speed change,and convenient operation.
l The power of the installation is large, with two reverse speed, which is convenient to deal with accidents.
l Equipped with normally closed hydraulic chuck, operation is flexible and reliable
l It can realized the independent operation of the vertical shaft and the hoist
l The diameter of the vertical shaft through the hole is large and can be replaced with a large six party active drill rod
2. The specifications of XY-3 bore well drilling machine
Drilling depth | 600m |
Borehole diameter | 300-75mm |
Maximum open hole diameter | 300mm |
End hole diameter | 75mm |
Drilling pipe diameter | 60 |
Drilling angle | 90°-65° |
Spindle | |
Rotating speed | 30-1050r/min |
Rotating stroke | 29-137r/min |
Stroke | 60mm |
Inner diameter | 96mm |
Lifting force | 6000kg |
Winch | |
Max.single line lifting speed | 0.5-1.9m/s |
Wire rope diameter | 12.5mm |
Max.single line lifting force | 4000kg |
Roll length | 50m |
Mud pump | |
Type | horizontal three cylinder BW-250 |
Displacement | 250L/min |
Work pressure | 80kgcm² |
Water inlet pipe diameter | 75mm |
Water outlet pipe diameter | 50mm |
Gear Oil pump | |
Duplex gear oil pump | CBF-F63/25 |
Displacement&pressure | 63l/min&20mpa |
Water outlet pipe diameter | 25l/min 20mpa |
Power | |
Diesel engine | 39kw |
Electric motor | 22kw |
Weight size | |
Weight | 1800kg |
Dimension | 2500*900*1800mm |
