Help CenterKY-200 Full Hydraulic Drilling Rig For Metal Mine Exploration
Related Products
-
KY-250mine Drilling Rig, Tunnel Prospecting Drilling Rig, Mine Core Drilling RigUS$ 4000 - 5500MOQ: 1 Set -
China High Quality BXZ-2 Double Knapsack Core Drilling Rig for SaleUS$ 4000 - 6000MOQ: 1 Set
-
BXZ-1 Portable Backpack Core Drilling Rig Operated By One PearsonUS$ 4500 - 5000MOQ: 1 Set
-
KQZ-200D Air Pressure and Electricity Joint-action DTH Drilling RigUS$ 4000 - 6000MOQ: 1 Set
-
KQZ-100D Air Pressure and Electricity Joint-action DTH Drilling RigUS$ 4000 - 6000MOQ: 1 Set
1.The brief introduction of KY-200 full hydraulic drill
KY-200 fully hydraulic tunnel drilling rig is widely used for tunnel and surface geological exploration, and can drill all hydraulic drills with arbitrary angle. The KY200 fully hydraulic drilling rig adopts the structure of all hydraulic power head, and consists of three parts: main engine, pump station and console. The breakage is good, transportation and transportation are convenient, drill rig layout is flexible, drill pipe unscrewing and unloading mechanization, it can reduce workers' labor intensity and improve work efficiency, and it can stepless speed regulation. KY-200 full hydraulic drill has the function of linkage. It is simple and safe through the control platform. The spindle of the gyration adopts the through hole structure. The length of the drill rod is not restricted by the drilling machine, and it can also be applied to the cored cored drilling.
2.The technical parameter KY-200 full hydraulic drilling machine
Drill pipe diameter (mm) |
φ33 |
φ43 |
Output torque (n.m) |
81-295 |
Borehole depth (m) |
200 |
160 |
Ability to feed (kn) |
27 |
Give a process (mm) |
850 |
Pullout ability (kn) |
20 |
|
Spindle speed (r/min) |
600-2000 |
Motor power (kw) |
22 |
|
