XY-200 Maximum borehole depth 200m core drilling rig/bore well drilling machine price in india
- 12 Set / Sets per Month
- Qingdao
- T/T L/C
- 7 days
-
China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
-
100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
-
HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
-
50m Depth Core Drilling Rig Portable Diamond in Mountain
-
TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
-
1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
| Brand Name: | HuaxiaMaster | Place of Origin: | China | Model Number: | XY-200 |
| Type: | Rotary Drilling Rig | Certification: | ISO-9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
| Warranty: | Six Months | Weight: | 800 KG | Dimension(L*W*H): | 2.1*1.3*0.9 M |
| Power Type: | Diesel | Voltage: | 380 V | Usage: | Water Well |
| Condition: | New | Power(W): | 13.2 KW |
Product Description
Keywords: hydraulic water drilling machine price, water borehole drilling machine
1. The applications of XY-200 drilling machine
Water well,field irrigation well, engineering water well, precipitation well and so on; geological survey, geophysical exploration, road and high-rise building foundation exploration, wells, blasting holes and other drilling projects.
2. The Specifications of XY-200 drilling machine
Maximum opening hole diameter | 400mm |
Drilling depth | 200m |
End hole diameter | 75mm |
Drilling angel | 90-75° |
Dimension | 2.75X0.95X1.60m |
Drilling pipe diameter | 50mm |
Weight without power | 760kg |
Spindle | |
Spindle rotation speed | 71/142/310/20r/min |
Spindle stroke | 450mm |
Winch | |
Maximum lifting weight (single rope) | 2008kb |
Lifting speed | 17/35/75/160rm/s |
Wire-rope diameter: | 13mm |
Roll capacity | 35mm |
Mud pump | |
Type: horizontal single cylinder double action | flow：180L/min |
Maximum pressure | 1.5mpa |
Working pressure | 0.7mpa |
Inlet pipe diameter | 50mm |
Outlet pipe diameter | 45mm |
Power | |
Diesel | 20hp |
Rated speed | 2200r/min |
Electric motor | 15kw |
Rated speed | 1460r/min |
