Product Details
| Brand Name | CARE | Model Number | MC-275B stainless steel square tube cutting machine |
Product Description
MC-275B High speed pneumatic stainless steel square tube cutting machine/hs code pipe cutting machines
Main specification
1.Manual feeding, Automatic clamping and Cutting
2.Can be realized angle cutting
3.Material Available: Carbon Steel,Stainless Steel,Copper etc.
4.Cutting Shape Available: Round,Square,Rectangle,Solid bar,other profiles...
5.Small Noisy
6.Good cutting quality for tube internal and external without burs.
7.Water cooling and lubricate system prolongs the life of machine and saw blade.
8.Good mechancial parts ensure machine runs in high stability.
9.CE, ISO9001 Certification
Cutting capacity
Machine model | MC-275 Series | MC-315 Series | ||
Cutting direction | 90 degree | 45 degree | 90 degree | 45 degree |
Hollow pipe | 80 | 60 | 100 | 80 |
Hollow square steel | 60×60 | 45×45 | 90×90 | 80×80 |
Hollow rectangular pipe | 60×80 | 45×60 | 80×90 | 80×80 |
Solid rectangular steel | 60×60 | 45×45 | 90×90 | 80×80 |
Solid shafting | 38 | 25 | 55 | 45 |
Solid square steel | 38 | 25 | 50 | 40 |
Technical parameter
Main pump | two-speed electric motor 2/2.4kw | two-speed electric motor 2/2.4kw | ||
Principle axis | RPM60/120 | RPM60/120 | ||
Applicable saw blades | OD 250/275 mm | OD 250/275/315 mm | ||
Cooling pump | 90W | 90W | ||
Air compression | 0.4~0.6MPa | 0.4~0.6MPa | ||
Machine weight | Type A | Type B | Type A | Type B |
180 | 190 | 200 | 210 | |
Machine photo
Pipe sample
Automatic type cutting machine
To know more information, please contact us at any time.
