Product Details
| Brand Name | CARE |
Product Description
Semi pneumatic/aluminium profile cutting machine for 45 degree
Main features
Suitable for cutting various special-shaped non-ferrous metals, aluminum, Aluminum Alloy, copper, copper alloy, plastic, plexiglass (acrylic) and carbon fiber materials, especially suitable for aluminum doors and windows, light boxes, photo frame, screen, electronic parts, heat sink, audio panels, video card, network card, CPU, hard disk, MP3 aluminum shell U disk shell, aluminum shell, plastic steel, wood, aluminum extrusion, paper tube and profile of precision cutting.
1. Only press the foot padel, machanical automatically press material, automatic cutting, that is safe and easy
2. Hidden type saw blade from top to bottom, can be single or multiple materials simultaneously cutting
3. According to the size and thickness of the material, set the height and speed of the material, cutting height and speed
4 Precision forced fuel injection system to improve the lubrication and cooling effect, reduce the failure rate to extend the life of the saw blade cutting off the surface without burr
PS: vacuum cleaner (optional)
Technical parameter
Spec. | MC-500L |
Sawing angle | Any angle |
Max. sawing width | 280mm |
Max. sawing thickness | 150mm |
Rotate speed of sawing shaft | 3800RPM |
Sawing speed | 10-15cyle/min |
Working area | 700×730mm |
Working height | 830mm |
Motor power | 5.5kw |
Needed pressure | 5-6kg/cm |
Length of feeding frame | May be made to order. |
Size of machine | 700*730*1200mm |
Size of container | 750*800*1270mm |
Net/gross weight | 650/680kgs |
Machine photo
Pipe/profile sample
