USB to 485 Converter RS485rs422 to USB Serial Port Module Usb to Rs485 Serial Db9 Cable Driver
US$ 6.98 - 9.98
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
CARATAR
Place of Origin:
China
Model Number:
Usb-rs485-1500-bt
Payment & Shipping
Payment Methods:
Port of Shipment:
sz or hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Ftdi Usb Rs485 to m8 M12 Serial USB-RS485-M12 Conversion RS485 M12 Usb to Rs485 Rs422 Usb Converter CableUS$ 6.98 - 12.98MOQ: 1 Piece -
FTDI Chip Usb to RS485 Cable With TX/RX LEDs, Wire End, 1.8MUS$ 6.98 - 7.98MOQ: 1 Piece
-
Ftdi Usb Rs485 to m8 M12 Serial Conversion Cable RS485 M12 TO USB CABLEUS$ 8.98 - 12.98MOQ: 1 Piece
-
USB-RS485 Converter Cable Provides a USB to RS485US$ 5.98 - 9.98MOQ: 10 Pieces
-
High Quality Ftdi Usb Rs232 Cable Usb Rs485 to Rj11 Cable,RJ45,8P8C,10P10CUS$ 5.98 - 9.98MOQ: 10 Pieces
Brand Name
CARATAR
Place of Origin
China
Model Number
Usb-rs485-1500-bt
Number of Conductors
6
rs232 to rs485 db9 converter Serial RS232 DB9 to DB25 cable male to female high speed parallel converter cable
Product Description
The CA-890 is a universal USB/RS-485/422 converter that converts single-ended USB signals to balanced differential RS-422 or RS without the need for an external power supply, USB compatible, RS-422, and RS-485 standards. -485 signal, providing surge protection power per line, and surge voltage generated on the line for various reasons and extremely small inter-electrode capacitance to ensure high-speed transmission of RS-422/RS-485 interface, RS-422, RS- The 485 terminal is connected through the connectors of the RJ-45 and DB9 male connectors. The converter has zero delay automatic transmission and reception conversion, and the unique I/O circuit automatically controls the data flow direction without any handshake signal (such as RTS, DTR, etc.) without jumper setting to achieve full duplex (RS- 422), half-duplex (RS-485) mode conversion, plug and play. Make sure it is suitable for all existing communication software and interface hardware.
The CA-890 interface converter provides reliable connections for point-to-point, point-to-multipoint communications. Each point-to-multipoint converter allows 32 RS-422 or RS-485 interface devices to be connected, with a data rate of 300. -128000bps with power indicator and data flow indicator to indicate fault conditions. Supported communication methods include USB to RS-422 and USB to RS-485 conversion.
Fully compatible with USB (Universal Serial Bus) Rev 2.0
Support RS-485/422 interface
RS-422/485 interface DB9 pin connector
Data (TXD) automatic flow control, zero delay design
Data transmission rate above 1Mbps
Support automatic handshake protocol
Support remote wakeup and power management
USB bus directly takes power, no external power supply required
+/-15KV ESD anti-static protection
Operating environment: -25 ° C to 70 ° C, relative humidity of 5% to 95%
Support Win98/Win2000/WinXP/Vista/Win7/Linux, etc.
The CA-890 interface converter provides reliable connections for point-to-point, point-to-multipoint communications. Each point-to-multipoint converter allows 32 RS-422 or RS-485 interface devices to be connected, with a data rate of 300. -128000bps with power indicator and data flow indicator to indicate fault conditions. Supported communication methods include USB to RS-422 and USB to RS-485 conversion.
Fully compatible with USB (Universal Serial Bus) Rev 2.0
Support RS-485/422 interface
RS-422/485 interface DB9 pin connector
Data (TXD) automatic flow control, zero delay design
Data transmission rate above 1Mbps
Support automatic handshake protocol
Support remote wakeup and power management
USB bus directly takes power, no external power supply required
+/-15KV ESD anti-static protection
Operating environment: -25 ° C to 70 ° C, relative humidity of 5% to 95%
Support Win98/Win2000/WinXP/Vista/Win7/Linux, etc.
| Baud Rate: | 3Mbaud |
| Cable Length - Imperial: | 5ft |
| Cable Length - Metric: | 0.5m 0.9m 1.5m 3m or Customized |
| Chip Type: | FT232R |
| Conversion Type: | USB to RS485/rs422 Converter |
| Converter Connector Type: | Free / Stripped End |
