Crawler Anchoring Well Hole Drilling MDL-100 Multipurpose Drilling Rig price
Applicaiton
MDL-150 is full hydraulic anchoring machines. It is used for supporting and protecting basic/medium pits, ensuring displacement of buildings, and avoiding geological hazard. It can move fast with the crawler, automatically disassemble rods and casing, reducing labour works and improving efficiency.
Features
1. The machine cover: scientific design can protects key components from pollution.
2. Landing leg: protect hydraulic cylinder and strengthen intension.
3. Split type operating platform: makes engineering easier and operation correctly.
4. Crawler: longer and stronger, effectively avoid sinking onto the ground and suit in more soil formation.
5. Big diameter high pressure water hose.
6. Power head: be drove by double hydraulic motors with big torque. Head center is lower than similar products, greatly improve rig balance. The attached streching kit can make rod thead use much longer.
7. Heat dissipation: be optimied to ensure highest temperature not exceeding 70 degrees when in outdoor temperature of 45 degrees.
8. (optional) lifting system: adjustable for hole hight, not just relying on the operating platform.
9. (optional) Automatic table makes less labour work and more convenience.
Specifications
Model: MDL-150
Drilling depth(m): 130-170
Hole diameter(mm): 150-250
Drilling rod diameter(mm): 73,89,102,114
Drilling angle(°): 0°-90°
Moving speed(km/h): 20
Climbing angle(°): ≤25°
Transport dimension(L*W*H)(mm): 5400*2100*2000
Weight(Kg): 6500
Power head
Output rotary speed(r/min): 10,20,30,35,40,60,65,70,85,130,170
Output torque(N.m): 7500
Stroke(mm): 3400
Lifting force(kN): 70
Lifting speed(m/min): 0-10(adjustable),14,46,59
Feeding force(kN): 36
Feeding speed(m/min): 0-10(adjustable),14,46,59
Optional matching power
Diesel(kW): 96
Electric(kW): 55+18.5
