Features:
1. High quality infrared laser diode 808nm 300mw
2. Laser diode
3. TO18-5.6mm package type
Wholesale 808nm 300mw TO56 IR wavelength Laser Diode
Excellent beam quality High stability Advanced technology Long Lifetime
Absolute Maximum Ratings (Tc = 25ºC)
| Item | Symbol | Ratings | Unit |
| Optical output power | Po | 300 | mW |
| LD Reverse Voltage | VR(LD) | 2 | V |
| Operating Temperature | Topr | -10 ~ +40 | °C |
| Storage Temperature | Tstg | -40 ~ +80 | °C |
Optical and Electrical Characteristics (Tc=25°C)
Parameter |
Symbols |
Conditions |
Min |
Typ |
Max |
Units |
|
Threshold Current |
Ith |
- |
- |
50 |
70 |
mA |
|
Operating Current |
Iop |
Po=300mW |
- |
350 |
370 |
mA |
|
Operating Voltage |
Vop |
Po=300mW |
- |
1.8 |
2.1 |
Volts |
|
|
Slope Efficiency |
η |
- |
0.8 |
1.0 |
- |
mW/mA |
|
- | |||||||
|
Beam Divergence (FWHM) |
Parallel |
θ‖ |
Po=300mW |
9 |
12 |
15 |
deg |
Perpendicular |
θ⊥ |
Po=300mW |
28 |
30 |
35 |
deg |
|
Parallel Deviation Angle |
△θ‖ |
Po=300mW |
-3 |
- |
3 |
deg |
|
Perpendicular Deviation Angle |
△θ⊥ |
Po=300mW |
-3 |
- |
3 |
deg |
|
Emission Point Accuracy |
△X,△Y,△Z |
Po=300mW |
-80 |
- |
80 |
um |
|
Lasing Wavelength |
λp |
Po=300mW |
805 |
808 |
811 |
nm |
|
Description:
1. Multi Transverse Mode laser diode.
2. Wholesale TO56 808nm 300mw IR wavelength laser diode.
3. Plastic box,standard and normal package.
Welcome your inquiry
TO: Ms. Elin
Mob: +86 18002689266
Dongguan BU Laser Co., Ltd
Shipping:
1.1-3 days after receiving the payment by T/T, PAYPAL.
2. It will be shipped by DHL/FedEx/UPS/TNT or other special ways, please contact us to choose the best one.
3. Delivery time will be usually 3~5 working days.
Company Information&Services:
A. Main products: Semiconductor laser diode, laser module, bicycle laser light.
B. Since the establishment, DongguanBlueuniverse Laser Co., Ltd has its own brand "LANJI, VIAN", access to China's outstanding semiconductor laser supplier reputation, with a number of domestic and foreign technology patent certification, product quality inspection certification and TUV, BV, SGS, ISO9001: 2015 quality management system certification.
FAQ:
Q: How to contact us?
Warranty:
All products have been tested before the shipment and it was packaged in good condition. Please tested the products at first before you assemble it, if any problem here, please inform us within 3 days of receipt. We can arrange the replacement for you if the situation is confirmed.
