Product Details
| Brand Name | HIENCE | Place of Origin | Shandong, China | |
| After-sales Service Provided | Engineers available to service machinery overseas | Condition | New |
Product Description
Small vertical universal drilling and milling machine for sale
Specification | Units | ZX6350ZA |
Spindle taper | 7:24 ISO40 | |
Max drilling dia | mm | 50 |
Max vertical milling dia | mm | 25 |
Max boring dia | mm | 120 |
Max tapping dia | mm | M16 |
spindle travel | mm | 120 |
vertical spindle center to column | mm | 200--500 |
vertical spindle nose to table | mm | 90--380 |
Horizontal spindle nose to table | mm | 0--290 |
spindle speed range | r.p.m | 115--1750(8 steps)40--1300(12 steps) |
table size | mm | 1250*320 |
table travel | mm | 600*300*290 |
T slot | 3*14*70 | |
main motor power | kw | 0.85/1.5(V)2.2(H) |
coolant pump motor power | W | 40 |
Overall size | mm | 1680×1480×2150 |
N.W/G.W | kg | 1450 |

Applications of CNC machine tool has been from the airline industry sector gradually expand to the automobile, shipbuilding, machine tools, construction machinery manufacturing industry.
For copper, aluminum , iron, plastic and other precision parts manufacturing, applicable to instruments , watches, cars, motorcycles , bicycles , eyewear , stationery , hardware, sanitary ware, electronic components , connectors , computers, cell phones , electronics, military and other industries in bulk machining small parts, especially the more complex parts.
The company has carried out ISO QMS, We according to the Europen CE certificate classified the production process in programmable.All the produce of parts by CE directive supervise each process. Our machine High- speed , highprecision, small cnc lathe machine, mini cnc lathe machine. There are heavy duty cnc lathe machine.
The proucts sell well in the domestic maket, and menwhile, they have been exported to Europe,America, Southeast Asia and othe countries,more than 50 countries in Worldwide.
The company adjacent to three estuaries of Qingdao ,Shanghai lianyungang Port as well as qingdao, jinan,shanghai Airport.
