The good quality radial drilling machine ZQ3032 Cutting machine tool drilling machine
- 50 Set / Sets per Month
- Qingdao shanghai tianjin lianyungang etc
- T/T Credit Card
- Lifting Milling And Drilling Machine ZX6350D Vertical Knee-type Milling
- Multifunctional drilling milling machine ZX7550CW
- ZX7550C CE Certificated Mini Bench Milling Machine
- Pedestal type drilling milling machine ZX6350ZA
- Lamp stand type drilling and milling machine ZX6350D
- Foundation drilling milling machine ZX7550CW
Product Details
Brand Name: | HIENCE | Place of Origin: | Shandong, China | Model Number: | ZQ3032 |
After-sales Service Provided: | Engineers available to service machinery overseas | Condition: | New |
Product Description
ZQ3032 Radial Drilling Machine
Items | ZQ3032×10 |
Max drilling diameter (mm) | 32 |
Distance between spindle center line and column(mm) | 200-910 |
Distance between spindle nose and work table(mm) | 330-1060 |
Distance of headstock horizontal movement(mm) | 710 |
Elevating distance of rocker(mm) | 730 |
Spindle taper | MT4 |
Spindle speed series | 6 |
Spindle speed | 108-1000 |
Spindle travel(mm) | 120 |
Spindle feeding speed(mm/r) | 0.10; 0.16 0.25 |
The rise and fall speed and spindle (r/min) | 1.21 |
The turning angle of rocker | ±180° |
The spindle allowed maximum torque (Nm) | 200 |
The spindle allowed maximum feeding resistance(N) | 5300 |
Main motor power(kw) | 1.5/2.2 |
Elevating motor power(Kw) | 0.55kw |
Coolant pump power (kw) | 0.04 |
Weight (kg) | 1080 |
Overall dimension | 1400*660*2060 |
