Stainless steel double bag filter

Double filter

Definition of double filter

Duplex filter is also called dual switch filter. It is made up of two stainless steel filters. It has many advantages, such as novel and reasonable structure, good sealing performance, strong circulation ability and simple operation. It has wide application and strong adaptability. In particular, the side leakage rate of the filter bag is small, which can accurately guarantee the accuracy of filtration, and can quickly replace the filter bag. There is basically no material consumption in the filtration, so that the operation cost is reduced.

Working principle and structure characteristics

Double filter is also called parallel switching filter, using two three ball valves, two single cylinder filter assembly in a frame, without cleaning the filter, ensure the continuous work, would not stop production line filtering device is preferred, filter element of the filter, in addition to the use of stainless steel filter, can also be adopted a high quality cellular skim fiber cotton, can filter out diameter of more than 1 mu of particles, the filter can be used in single cylinder, just remove the common base, the rest of the same size.

The inside and outside surfaces of the duplex filter are polished. The stainless steel filter screen and filter basket are installed in the filter cartridge, and the vent valve is arranged at the top to filter the air in the filter when it is filtered. The upper cover and the filter tube are connected with the fast opening structure, which is more convenient for cleaning (replacing) filter net. Three adjustable legs can make the filter put on the ground smoothly. The connection pipe is connected by movable connection or hoop connection. The inlet and outlet valves are opened and closed by three way ball valves, withstanding pressure and temperature, flexible and convenient operation, and no liquid leakage is more sanitary.

The duplex filter is made of stainless steel. It is made up of two cylinders. It is made up of single stainless steel welded structure. The inside and outside surfaces are polished, and the top is equipped with bleed valve for discharging when working. The pipe joint is connected by expansion and closing. Through 0.3Mpa water pressure test, the three through screw plug is flexible. The equipment is compact, easy to operate and simple in maintenance.

The scope of application of double filter

1, chemical and petrochemical production of weak corrosive materials, such as water, ammonia, oil, hydrocarbon and so on.

2, chemical production of corrosive materials, such as: caustic soda, concentrated sulfuric acid, carbonate, acetic acid and so on.

3, refrigeration in low temperature of the material, such as: liquid methane, ammonia, oxygen and refrigerant.

4, light industrial food, pharmaceutical production of sanitary materials, such as: beer, beverages, dairy products, grain and slurry pharmaceutical products.

Size and technical parameters

1.: 0.15 square meters, the filtering area of 0.30 square meters,

2. filter ability: 3t/h, 5t/h, 10t/h;

3.: the suitable temperature is not higher than 120 deg;

4. filter mesh size: 60~400 mesh (for selection);

5. working pressure: 0.2MPa;

6. filter material: 304/316L;

7. import and export pipe diameter: 32mm, 40mm;

8. internal and external surface treatment: inner mirror polishing, external mirror polishing or sub light　　

Installation and use

　   When the installation is used, the protection of the control box, the sensor and the transmission part should be paid attention to, and the damage should be prevented.

According to the arrow pointing direction of the stainless steel self cleaning filter

When adjusting the electric part, please note that the rotation direction of the motor should be the same as the direction of the motor.

The installation should be considered for easy maintenance and the bypass pipe should be installed.

When installing, we should consider the bottom of the discharge outlet as far as possible, so as to facilitate the discharge of the sundries.

The discharge pipe receives the draining ditch, and the sewage pipe should not be too long.
