Automatic Stirred Tank Reactor
1. Brief Introduction :
(1)Reaction pot consists of pot body, pot, mixer, jacket, bearing and gear, shaft sealing device, etc, the material and open hole can be formulated according to the requirements of the user process.Heating with electric heating, oil heating, gas heating, water heating (or cooling), firing, etc.Jacketed form is divided into: model and the outer tube type, jacket type oil heating have guiding device.Is usually stirring paddle,
anchor, box type, screw type, wall, etc.High speed class has dispersion impeller type, turbine, high shear type, propeller type, for the customer to choose according to the craft.Drive mode with general motors, explosion-proof motor, electromagnetic speed regulating motor, frequency converter, heat exchanger has a cycloidal needle wheel, worm gear, planetary CVT.Shaft seal for the common water cooling packing seal, combined ptfe packing seal, mechanical seal.Have a ball valve, the valve discharge form. Widely used in medicine, building materials, chemicals, paint, resin, food industries, heat quickly, high temperature resistant, corrosion resistance, health, no environmental pollution, no automatic boiler heating, convenient use, etc.
(2) The reaction kettle type contains the following elements:
1)Seal: mechanical seal, packing seal, oil seal, etc
2)Form: round head, single-layer, up and down jacket, outside dish tube, inside dish tube
3)Heating, heating, hot water, steam, heat conduction oil heating electrical heating, far red heat resistance
5)Mixing: generally speaking, there are the anchor type, impeller and turbine, pusher, or frame
2. Reaction Vessel Machine Parameters:
| model | NY-FYF-1 | HT-FYF-2 | HT-FYF-3 | HT-FYF-4 | HT-FYF-5 | HT_FYF-6 |
| Type | 50L | 100L | 300L | 500L | 1000L | 2000L |
| actual capacity | 78 | 127 | 327 | 509 | 1017 | 2154 |
| heating power | 2*4 | 2*6 | 4*6 | 4*9 | 4*12 | 4*15 |
| motor power | 1.1 | 1.1 | 2.2 | 3 | 4 | 5.5 |
| Speed/speed ratio | 85/17 | 85/17 | 85/17 | 85/17 | 85/17 | 85/17 |
| Speed ratio/speed ratio | 63/23 | 63/23 | 63/23 | 63/23 | 63/23 | 63/23 |
| H | 1550 | 1690 | 1910 | 2320 | 2650 | 3200 |
