2018 best Norton Grinding Wheel Balancing Machines for tools
Production Description
• Specially designed,solid brackets can effectively transmit mechanical force
• Durable and reliable sensor possesses high sensitivity and good linearity
• Permanent calibration brings high accuracy
• Special clamp offers higher accuracy and easier operation
• .Advanced electrical measuring system and friendly man-machine interface
• As the customer's request,the de-weighting system can be equiped
Range of Application
The balancing machine is a new and widely-used device which has been available and developed in recent years. It is mainly applied to balance all kinds of discoid parts, such as fan blade, brake disk,brake drum.saw blade.clutch,belt pulley,chuck,pump impeller,flywheel,grinding wheel,range hood fan,brake, torque converter,tool etc .High speed and precision are advanages of this balancing machine.
According to user’s requirement,The machine can install de-weight device
Special Features
The measuring unit employs JP-580B Electrical Measuring unit is a system of top function and precisionIt can be applied in all kinds of single/double plate and hard/soft bearing machines, and can be connected with different velocity and pressure sensors easily. The unit adopts industrial computer mainboard which equiped with 15-inch LCD screen and 1G Memory, Electric board 4G, Windows XP Operating System. Featuring with high running speed and reliabilitystrong dustproof and shakeproof ability, it is applicable to various industrial environments.
Production Parameters
Technical data at a glance |
PHLD-16 |
PHLD-42 | PHLD-65 |
Max Mass of Workpiece (with clump) (kg) |
16 |
42 |
65 |
Max Diameter of Workpiece (mm) |
5101) 8002) |
5101) 8002) |
5101) 8002) |
Height of Workpiecemm |
160 |
160 |
160 |
Rotation Speed of Main Axis (r/min) |
900 |
800 |
700 |
Motor Power (kw) |
1.5 |
1.5 |
2.2 |
Min Achievable Residue Unbalace Amount (emar) |
5g· mm/kg |
5g· mm/kg |
5g· mm/kg |
1) With hood
2) Without hood
Factory Outlook
Certificates
Material inspection
Production Process-Measuring system
easuring system
Production Process-Mechanical parts
Workshop debugging
Delivery inspection
Package and transport
