Detailed Product Description
| Product Name: | Camera Link Cable | Sheath Material: | PVC |
| Range Of Application:: | Machine Vision Imaging | Type: | High Speed Data Cable |
| Conductor Material: | Copper | Conductor Type: | Solid |
| Material Shape: | Round Wire | 1meters: | 85MHz |
Camera Link Cable Special Custom Designed Screw Locking and Latch Type SCSI Cable Harness
Product Description:
Contact us and find out how we can meet your needs with cablesand assemblies custom designed for your application.
We have experienced RD department and skilled employees which have more than 10years in machine vision cable field
and know product specification.Quickly and accurately response to customer’s special requirements.
Cable length - Considering the placement of the camera relative to the host computer, what cable length is required to connect the camera to the frame grabber?our custom cable length from short camera link cable 15cm to long camera link cable 15meters.
Frame grabber connection - Does the frame grabber require a cable with an MDR (standard) or SDR (mini) Camera Link connector?please refer below our camera link connection type,the straight camera link connector,right angle camera link connector,screw locking camera link connector,latch lock camera link connector,PVC molding camera link connector and metal camera link assembly type.....
Camera connection - Does the camera require a cable with an MDR (standard) or SDR (mini) Camera Link connector?please refer below our camera link connection type.please refer below our camera link connection type,the straight camera link connector,right angle camera link connector,screw locking camera link connector,latch lock camera link connector,PVC molding camera link connector and metal camera link assembly type.....
-
PoCL - Is a PoCL (Power over Camera Link) cable required? we offer both standard CL and PoCL camera link for options.
Refer to the camera's User Manual to determine if the camera is PoCL compliant or if it requires an external power supply. When ordering a Camera Link cable (or frame grabber) for a PoCL camera, be sure your sales person knows your camera is PoCL compliant.
One or two cables - What does the connection between camera and frame grabber require?If the Camera Link camera is base configuration, then only one cable is required. If the camera is Medium, Full, or Extended (DECA) configuration, then two cables are required. Look at the back of the camera. How many Camera Link connectors are there?
SCSI connector,D-SUB connector,molded cable assemblies,Custom SCSI cable,SCSI cable assembly,
D-sub cable,camera link,Mini camera link,3M camera link cable,Waterproof cable,Molded cable assembly,
SAS cable assembly,Custom SAS cable,Custom camera link,Camera link cable,cameralink cable,camera link
Mini camera link,3M camera link cable,SDR cable,MDR cable,PoCL cable,pocl cable,camera link connector
cable,camera link,Mini camera link,Robotic camera link cable,PoCL robot cable,custom camera link cable
Camera link HS,cam link cable,link camera cable,pocl cable,cameralink cable,camera link,Robotic camera link cable
Ordering Information
Standard Cable
DHT Part Number |
Cable Length |
Cross 3M Part Number |
CL0050-MM |
0.5 meter |
14T26-SZLB-050-0LC |
CL0100-MM |
1.0 meter |
14T26-SZLB-100-0LC |
CL0200-MM |
2.0 meter |
14T26-SZLB-200-0LC |
CL0300-MM |
3.0 meter |
14T26-SZLB-300-0LC |
CL0500-MM |
5.0 meter |
14T26-SZLB-500-0LC |
CLA000-MM |
10.0 meter |
14T26-SZLB-A00-0LC |
High Flex Cable
DHT Part Number |
Cable Length |
Cross 3M Part Number |
CL0050-MM(R2) |
0.5 meter |
14T26-SZLB-050-SKC |
CL0100-MM(R2) |
1.0 meter |
14T26-SZLB-100-SKC |
CL0200-MM(R2) |
2.0meter |
14T26-SZLB-200-SKC |
CL0300-MM(R2) |
3.0 meter |
14T26-SZLB-300-SKC |
CL0500-MM(R2) |
5.0 meter |
14T26-SZLB-500-SKC |
CLA000-MM(R2) |
10.0 meter |
14T26-SZLB-A00-SKC |
