Detailed Product Description
| Product Name: | Camera Link Cable | Application: | Industrial Camera |
| Cable Length: | 5.0 Meters | Interface: | Full Camera Link |
| Connector: | MDR26pin To MDR26pin | Feature: | High Flex,Chain Flex |
| Standard: | CE/ROHS/FCC/SGS | Type: | Molding,Screw Lock |
Hiflex PVC Camera Link Cable MDR 26pin Male to MDR 26pin Male Non PoCL with Thumbscrew Locking for Dynamic Application
Product Description:
1, Customized Industrial Camera Data Cable 3M, Iron Shell Assembly MDR Connector,with POCL power over Camera Link cable for options.
2, High-speed types are suitable for a clock frequency @85MHz
3, Cable is a high flex straight camera link cable.The cable construction adheres to Camera Link specifications and are Certified to Camera Link Committee Standards. By combining the most advanced materials and sophisticated building techniques, we provides the high flex industrial assemblies available,including Camera link,USB, U3,Firewire,Gige Vision,Hirose series cable assemblies. These assemblies are designed to function within a broad range of temperature and environmental conditions and may be used in either static or flex applications.
4, Max Length 15meters High speed transmission well shielded,low attenuation,low noise
5, Hiflex,can be used in chain system.
7, Working temperature -40℃~+80℃
8, Confirms to the UL standard,confirms to RoHS directives
8, Confirms to the CAMERA Link interface specifications and compatiable with all industrial camera with camera link interface
Physical |
Cable Color |
Black |
Connector |
3M MDR26 |
|
Jacket Material |
UL 80℃ PVC |
|
Shell Material |
Polyester Elastomer |
|
Shell Color |
Black |
|
Shell Construction |
Pre mold in Poly Ethelene wrapped 360 degrees with copper tape terminated to shield, overmolded in black PVC. |
|
Cable construction |
Meets Automated Imaging Association(AIA)Camera Link Standard. 11 Pairs Tinned Copper Wire UL20276(28AWG*2C+AM)*11PCS+4D+TEFLON+FAM+BRAID,OD9.5MM, BLACK PVC JACKET. Skew (within pair): 35 ps/meter maximum Skew (Channel skew per chipset): 50 ps/meter maximum All cables are Camera Link approved. |
|
|
Electrical |
Voltage Rating |
30V |
Current Rating |
1A |
|
Insulation Resistance |
Max. 237 ohms/km at 20℃ |
|
Dielectric Test |
500 VAC /1 min ; No Breakdown |
|
Impedance |
Nom.100 � 10 ohms |
|
Delay Skew |
50 ps/meter maximum |
|
Temperature Rating |
- 40 to +80 Celsius degree |
|
Applications:
Indutrial Camera |
DALSA,BASLER,COGNEX,CORECO,ADIMEC,EURESYS,JAI,IMPMEX,MATROX, DTA,PULNIX,EVISION,PLEORA,TOSHIBA TELI,NATIONALINSTRUMENT,REDLAKE,UNIQ,IDT,DVC,SILICONIMAGING,OMRON, PELCO,SENTECH,EPIX…… |
Imaging frame grabber |
CORECO,EPIX,EURESYS,FORESIGHT,MATROX,EVISION,NATIONAL INSTRUMENT…… |
Machine vision |
For all Camera Link standard interface |
Equipment Systems |
Automatic Optical Inspection system(AOI), Mould monitor, Robot device,Machine Arms,Medical Equipment,Factory Equipment |
