Detailed Product Description
| Length: | 3M | Color: | Black |
| Interface: | 90 Degree SDR 26PIN | Application: | Machine Vision |
| Hi-Flex: | Yes | Guarantee: | 1~2years |
3M Camera Link 26Pin SDR Right Angled Male Cable Assemblies 90 degree R/A 1SF26-L136-00C-300 SDR/HDR
Product Description:
1SF26-L136-00C-300 with 90 degree Camera Link interface 26pin SDR / HDR Angled Male connector,the angle orientation options: right angle up and right angle down,right angle left and right angle right exit.
With Power over Camera Link for options,all material from USA Japan and Taiwan brand supplier,3M original connector to confirm the 85MHZ high speed transmission,short cable length 0.3meters,long cable length 10meters, the cable body is robust, ultraflex for chain system,can work in -40℃ ~+ 80℃,30AWG cable type OD 8.0mm,28AWG cable type OD 9.5mm.
We have many solution for machine vision data transmission and connection to solve the complex problem,worth of your contacting.welcome.
Tips:
1SF26-L136-00C-300
20 = SDR straight to SDR straight backshell.
36 = The direction of the cable for the RA SDR connector dresses down with
respect to a horizontal board mount connector. The topology for the 36 option is
a straight overmolded SDR backshell to a R/A overmolded SDR backshell.
37 = The direction of the cable for the RA SDR connector dresses up with respect
to a horizontal board mount connector. The topology for the 37 option is a
straight overmolded SDR backshell to a R/A overmolded SDR backshell.
Compatiable part number:
| 1SD26-3120-00C-200 |
| 1SD26-3120-00C-300 |
| 1SD26-3120-00C-500 |
| 1SD26-3120-00C-A00 |
| 1SF26-L120-00C-100 |
| 1SF26-L120-00C-200 |
| 1SF26-L120-00C-500 |
| 1SF26-L120-00C-A00 |
| 1SF26-L136-00C-100 |
| 1SF26-L136-00C-200 |
| 1SF26-L136-00C-500 |
| 1SF26-L136-00C-A00 |
| 1SF26-L137-00C-100 |
| 1SF26-L137-00C-200 |
| 1SF26-L137-00C-500 |
| 1SF26-L137-00C-A00 |
