Camera Link Coupler / Extension / Adapter Cable Female 26-Pin MDR Receptacle to Male 26-Pin MDR / SDR / HDR
Product Description:
1, 26 Pin straight SDR Male and MDR Female
2, Non Power and Power over Camera Link Connection Type available
3, Camera Link Coupler / Extension / Repeater / Adapter Cable Assembly.
4, For applications where a feed through cable is required, you may use this MDR26 plug to MDR26 receptacle cable for gender changing or cable extention.We usually carry 0.5,1.0,1.5,2.0meter in stock.
* How to use Camera Link Extensinon Cable?
* CCD Camera --> Camera Link Extension Cable --> Camera Link MDR-MDR Cable.
Specifications:
Color | Black |
Outer Diameter | 8.0 ± 0.1 mm |
Temperature Rating | 80°C (per UL20276) |
Conductor Resistance at 20C | less than 240 W/km |
Insulation Resistance | over 100 MW-km |
Withstanding:Voltage | 350 VAC for 1 minute |
Voltage Rating | 30 VAC |
Characteristic Impedance | 100 ± 10 W |
Propagation Speed | 4.7 ns/m ± 10% |
Skew (within pair) | 50 ps/m maximum |
RoHSCompliant | Yes |
Available length are listed below:
| DHTCL0050-MF | MDR26 plug to MDR26 receptacle ,0.5 meter |
| DHTCL0100-MF | MDR26 plug to MDR26 receptacle ,1.0 meter |
| DHTCL0150-MF | MDR26 plug to MDR26 receptacle ,1.5 meter |
| DHTCL0200-MF | MDR26 plug to MDR26 receptacle ,2.0 meter |
