Detailed Product Description
| Cable: | 11 Individually Shielded Twisted Pairs | Connector: | 26 Pos MDR Or SDR (HDR) Straight Or Right Angle |
| Color: | Black | Locking Type: | With Screw |
| Length: | 1~10meters | High Flex Cable: | Yes |
DHT camera link right angle cable is according to Camera Link AIA Committee Standards. we can provides the robust industrial assemblies available. These right angles are designed to function within limited equipment space and the robust features can be used to the equipment of temperature and environmental conditions and may be used in either static or flex applications.
The unique right angle overmolding available in up, down, left and right orientations allows for immediate turns behind the interface that are specific to your application needs eliminating the need for minimum bend radius concerns. The common configuration consists of a right angle on the camera end and an overmolded straight connector on the equipment end. However both connectors are available with a right angle.
Our High Flex extension cables offer system versatility and convenience when required to extend your current cable length. Both the plug and the receptacle connectors feature durable overmolded strain reliefs. The receptacle end is completed with 4/40 jacknuts to ensure locking and proper, constant connection through motion and vibration. Right angle and low profile right angle assemblies are also available in the extension format.
The latch style locking offers a quicker connect/disconnect time for the plug end than standard thumbscrews. Cables are available with latches on both ends and with latches on one end and thumbscrews on the other.
Connector type for options:
| camera link cable right angle MDR to MDR |
| right angle mini camera link cable SDR to SDR |
| right angle camera link cable MDR to SDR |
| right angle camera link connector Female connector |
- Cable: 11 Individually Shielded Twisted Pairs
- Designed to surpass 5 million flex cycles
- AIA Certified
- Robust High Flex cable
- Low skew
- Long distacne
- OEM
- 360 Degree shielding
- Right angle interfaces
- Quick latch style locking
RoHS Compliant
DHT Camera Link Connections:
Durable overmolding
Thumbscrew locking
Connector A: 26 Pos MDR or SDR (HDR) Straight or Right angle
Connector B: 26 Pos MDR or SDR (HDR) Straight or Right angle
