Full Automatic 4 Color Flexo Label Printing Machine
This 4 colour flexo label printing machine is fit for flexo printing of label paper,plastic label, commercial forms, computer typing paper, food packing paper, plastic film etc, the printing quality is high and cost effective for the flexo plate. This flexo printing equipment use water based ink, it is green equipment so widely accepted by printing and packaging industry.
Features:
1.Use high precision ceramic anilox cylinder for ink transfer
2.Unwinding adopts magnetic brake and Mitsubishi tension controller
3.Rewinding adopts magnetic clutch and reliable tension controller
4.Printing unit 360° plate register adjustment
5.IR dryer for each printing unit
6.The anilox roller will be separated with plate roller and still keeping low speed running after machine stopped
7.Imported frequency inverter for speed control
8.With laminating unit and rotary die cutting unit
9.Optional parts: UV dryer, web guide, turn-bar, rotary die cutting station, video camera etc.
10.320mm, 450mm, 620mm, 820mm width available, other size can be special made
11. Stack type so can save floor space for printing house.
Main specifications:
Model |
FP-320 |
|
Printing speed |
50m/min |
|
Printing color number |
4, 5 or 6 |
|
Max. web width |
320mm |
|
Max. printing width |
310mm |
|
Max. unwinding diameter |
600mm |
|
Max. rewinding diameter |
600mm |
|
Printing repeat length |
175-355mm |
|
Precision of color register |
±0.1mm |
|
Overall dimensions |
2X1.1X2.7M |
|
Weight |
About 2500kg |
|
Kingsun Company also boasts its 14 more years of experience in supplying a variety of printing and packaging machinery and materials, so we deliver goods worldwide, our teams are all university graduated and constantly with professional training with energetic and positive attitude, so we fully understand how to provide high-quality products and better services to our global customers. We continuously improve our organizational management, adopt the most advanced technologies and software system, so we have been keeping the pace with the leading position in the industry.
Kingsun Company has 15 more manufacturing factory bases, each factory focus on one or a few kind of specific printing and packaging machines production, as a result, we have the ability to meet different needs from different buyers, this way can take advantage of our machinery group and each of factory can play its own marketing or manufacturing strengths.
Our team has accumulated so many years of experience for printing and packaging machinery industries, we also have established a specialized after-sales service team and R&D team, so that we can provide our buyers with better machines and services.
