Double Mitre Automatic Pendulum Aluminum Cutting Saw Machine
Our LJZ2-500*4200 Double Mitre Automatic Pendulum Aluminum Cutting Saw Machine uses an automatic system for driving and feeding. Characterized by fine cutting size, convenient operation, reliable operation and advanced technology. The hard alloy cutter of this double mitre cutting saw is marked by high cutting speed and high production efficiency. This cutting saw is also a kind of ideal machine for processing aluminum doors and windows.
This style of aluminum door window machine uses exported metal saw blades. Characterized by high precision and high cutting efficiency, this cutting machine can be used to cut aluminum alloy profiles, with its cutting precision having already reached the world advanced level.
LJZ2-500*4200 Double Mitre Automatic Pendulum Aluminum Cutting Saw Machine Performance and Features:
1), Double mitre automatic pendulum left and right flip,especially for sawing short material function.
2), Imported straight feeding guide rail pair.
3), Motion of head by imported linear bearing pair.
4), Hydraulic damping cylinder drive the saw blade feed.
5), Large range of cutting. Maximum length up to 4200mm. And you can tailor it to your needs. Three cutting angle 90°, 45°, 22.5°
6), Shaft of saw blade made by professional maker.
LJZ2-500*4200 Double Mitre Automatic Pendulum Aluminum Cutting Saw Machine
Technical Parameters:
Power supply |
380V 50Hz |
Input Power |
4.4KW |
Working Air pressure |
0.5-0.8Mpa |
Blade rotational speed |
3100r /min |
Saw Blade specification |
D=500m d=30mm |
Cutting Length |
Min385mm Max4200mm |
Cutting angle |
90° 45° 22.5° |
Outside dimension(mm) |
5600mm×1750mm×1900mm |
Weight |
1700Kg |
Jinan Rebound Machine Co., Ltd China
http://
Skype/email:reboundcnc@gmail.com
Whatsapp：0086-132 9644 3055
QQ/WeChat：1303954009
