Digital tensile compression flexure shear universal testing machine
1. Specification
a. It is used to do tensile, compression, flexure, shear test for metal and non metal material.
b. It adopts underlying oil cylinder.
c. Test space is adjustable.
d. Four column structure.
e. Digital display.
f. High precision, easy operation.
2. Main technicial parameters
Model & Specifications | UTM-300D | UTM-600D | UTM-1000D | |
Capacity | 300KN | 600KN | 1000KN | |
Measuring accuracy | ±1% | ±1% | ±1% | |
Tensile space | 620mm | 680mm | 680mm | |
Thickness of flat specimens | 0-15mm | 0-30mm | 0-40mm | |
Diameter of round specimens | Φ10-32mm | Φ13-40mm | Φ20-60mm | |
Distance between bending rollers | 100-480mm | 100-660mm | 100-700mm | |
Diameter of shearing specimens | Φ10mm | Φ10mm | Φ10mm | |
Dimensions | Mainframe | 640×550×1800mm | 900×600×2200mm | 1060×760×2400mm |
Power | 1.5KW | 1.65KW | 2.25KW | |
Digital tensile compression flexure shear universal test machine
Digital tensile compression flexure shear universal test machine
The biggest manufactor is in china, the top quality is in china, the best service is also in china!
Pls believe GEOTEST, Believe China Power!
We sincerely lookinf forward to cooperate with you!
