ATM-6500 Load Anchoring Testing Machine
Characteristics:
Used for static-loading anchor testing testing for steel strand wires both of single-strand and muti-strand samples in sizes of Φ21.8mm,Φ17.8mm and Φ15.24mm.
It can detect both single-pore and muti-pore anchorage.
Adopting load and sensor to measure load,controlled and displayed by computer ,with high control precision.
With maintenance functions of max.load peak and displacement peck.
With overload protection function.
| Model | ATM-6500 |
| Measuring range | 4%-100% |
| Force accuracy | ±1% |
| Control rate of testing force | 1 KN/s-50 KN/s |
| Speed range | ≤±5% |
| Measuring range of displacement | 0-200mm |
| Displacement accuracy | ±1% |
| Repeatability | ±0.5% |
| Relative resolution | ±0.5% |
| Piston stroke | 200mm |
| Tensile space | 3400mm |
| Main frame dimensions | 5030x700x2060mm |
| Control cabinet dimensions | 1180x800x1310mm |
| Power supply | 380V |
| Total power | 3.5KW |
| Weight approx | 4000kg |
