ATM-6500 Computer-controlled Static-load Anchor Testing Machine
Product Description
Characteristics:
a. Used for static-loading anchor testing for steel strand wires both of single-strand and multi-strand samples in sizes of Φ21.8mm, Φ17.8mm and Φ15.24mm.
b. It can detect both single-pore and multi-pore anchorage.
c. Adopting load sensor to measure load, controlled and displayed by computer, with high control precision.
d. With maintenance functions of max. load peak and displacement peck.
e. With overload protection function.
| Loading capacity | 6500KN | |||
| Measuring range | 4%-1000% | |||
| Force accuracy | ±1% | |||
| Control rate of testing force | 1KN/s-50KN/s | |||
| Speed range | ≤±5% |
|||
| Measuring range of displacement | 0-200mm | |||
| Displacement accuracy | ±1% | |||
| Repeatability | ±0.5% | |||
| Relative resolution | ±0.5% | |||
| Piston stroke | 200mm | |||
| Tensile space | 3400mm | |||
| Main frame dimensions | 5030x700x2060mm | |||
| Control cabinet dimensions | 1180x800x1310mm | |||
| Power supply | 380V | |||
| Total power | 3.5KW | |||
| Weight approx | 4000kg | |||
