TSRTM-300 Strand Wire Tensile Stress Relaxation Testing Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Geotest Equipments
Model Number:
TSRTM-300
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TTM-100 Computer-controled Electrical Torsion Testing MachineNegotiableMOQ: 1 Set -
ATM-6500 Computer-controlled Anchor Testing MachineNegotiableMOQ: 1 Set
-
UTM-300B Automatic Universal Testing Machine (Computer Control Electro-hydraulic Servo )NegotiableMOQ: 1 Set
-
Hydraulic Universal Testing MachineNegotiableMOQ: 1 Set
-
CTM-2000 Digital Concrete Compressive Strength Testing MachineNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
Geotest Equipments
Model Number
TSRTM-300
Power
Electronic
Usage
Universal Testing Machine
TSRTM-300 Strand Wire Tensile Stress Relaxation Testing Machine
Standard: ASTM E328-2000
Feature
a. Used in tensile stress relaxation performance test of metal materials (such as steel strand wire, PC steel rods and steel wires) under room temperature.
| Capacity | 300KN | |||||
| Measuring range | 2%-100% (same resolution in full range) | |||||
| Loading accuracy | ±1% | |||||
| Loading resolution | 0.05% FS | |||||
| Loading speed | 0.1-50mm/min (can be set freely) | |||||
| Initial loading method | automatic 70% or 80% breaking loading | |||||
| Loading program | automatic constant-speed, automatic record after maintenance for 2 minute | |||||
| Loading speed | 100-5000N/S (can be set freely) | |||||
| Sample size | Φ15.20mm | |||||
| Tensile stroke | 0-200mm | |||||
| Total tensile distance | 800-1000mm (can be designed according to requirements) | |||||
| Measuring range of displacement | 0.2%-100% | |||||
| Displacement accuracy | 0.001mm | |||||
| Structure of loading frame | horizontal loading frame | |||||
| Power | AC 380V, 50Hz (servo motor with braking) | |||||
| Overall dimensions | 2840x670x1060mm | |||||
| Weight approx | 1200kg | |||||
