Home > Instruments & Meters > Test Instrument > Test Machine > UTM-1000E Electro-hydraulic Servo Universal Testing Machine, 1000kN Hydraulic Universal Testing Machine UTM Price
UTM-1000E Electro-hydraulic Servo Universal Testing Machine, 1000kN Hydraulic Universal Testing Machine UTM Price
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GEOTEST EQUIPMENTS
Model Number:
UTM-1000E
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UTM-600AC Fully Automatic Universal Testing MachineNegotiableMOQ: 1 Set -
Stainless Steel Bending MachineNegotiableMOQ: 1 Set
-
UTM-300AT Analogue Universal Testing Machine (dial Guage Type)NegotiableMOQ: 1 Set
-
TSRTM-300 Strand Wire Tensile Stress Relaxation Testing MachineNegotiableMOQ: 1 Set
-
TTM-100 Computer-controled Electrical Torsion Testing MachineNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
GEOTEST EQUIPMENTS
Model Number
UTM-1000E
Power
Other, Electro-hydraulic Servo
Usage
Universal Testing Machine
UTM-1000E Electro-hydraulic Servo Universal Testing Machine, 1000kN Hydraulic Universal Testing Machine UTM Price
Characteristics:
Using microcomputer controlled high precision electro-hydraulic servo valve to drive precise hydraulic cylinder and can realize constant speed control to test force, displacement, deformation, etc. and so that to make tensile, compression, bending tests.
Protection functions:
a. limit position protection for oil cylinder
b. over current protection for hydraulic system
c. overload protection
d. over current, over voltage protection
e. safe protection at the time of specimen breaking
f. automatic protection after test
| Max.load (KN) | 1000KN | |||||
| Accuracy | Less than ±1% | |||||
| Measuring range | 2%-100% F.S | |||||
| Loading resolution | 0.1KN | |||||
| Max. tensile space (including piston stroke) | 700mm | |||||
| Max. compression space | 580mm | |||||
| Span between columns | 620mm | |||||
| Max. clamping width of flat specimen | 70mm | |||||
| Clamping thickness of flat specimen | 0-40mm | |||||
| Clamping diameter of round specimen | Φ20-60mm | |||||
| Size of upper and lower platen | 240x240mm | |||||
| Overall dimensions (main machine) | 950x700x2350mm | |||||
| Overall dimensions (control cabinet) | 1100x670x930mm | |||||
| Power | 2.2KW | |||||
| Weight approx | About 3500kg | |||||
