2014 Hot Sale B50125 Heavy-duty Slotting Machine

2014 Hot Sale B50125 Heavy-duty Slotting Machine photo-1
US$ 120,000 - 140,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Liaoning, China
Brand Name:
MACH
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian Port China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Liaoning, China
Brand Name MACH
Model Number B50125
Power(W) 37kw
Dimension(L*W*H) 4600*3200*5300mm
Weight 26T
Certification CE
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

2014 Hot Sale B50125 Heavy-duty Slotting Machine


Product Description
Specification



Type

B50100

B50125

Max slotting length

1000mm

1250mm

Cutting stroke speed

4-25m/min

4-30m/min

Return stroke speed

7-25mm/min

7-35m/min

Max weight of slotting workpiece

4000kg

4500kg

Main motor

30kw

37kw

Max table slotting force

24500N

24500N

Working table diameter

 250mm

1400mm

Max traverse of worktable(Rotary 360°)

L:1200mm

 L:1400mm

H:1000mm

 H:1120mm

Distance between tool holding surface and column front

1120mm

1600mm

  Range of feed: Longitudinal

 0.2-5mm/double stroke

 0.2-3 mm/double stroke

                           Transverse

 0.5-5mm/double stroke

 0.2-3 mm/double stroke

        Circumference (in the Φ 700 circle)

 0.4-10mm/double stroke

 0.1-5 mm/double stroke

Distance between worktable and lower side

1140mm

1650mm

Table longitudinal and cross rapid traverse

500m/min

500m/min

Dimensions

4400*2830*5730mm

4600*3200*5300mm

Weight

22t

26t

2014 Hot Sale B50125 Heavy-duty Slotting Machine

Our Services



Guarantee & After-selling Service

We will supply enough spare parts and accessories with our machine when shipment. Within one year after receiving   our machine, If there are any damaged parts or accessoreis, We will supply them to you by air-mail FREE OF CHARGE.We will provide FULL MAINTENANCE & BACK-UP SERVICE for our clients after shipment. It's the basis of establishing long-term cooperation with our foreign clients.

Certificate

 CE certificate & ISO Certificate


Company Information
About our Company

Our factory is one of biggest professional manufactuer of producing Slotting Machines in China. Our  Slotting Machines are exported to many countries. Such as:  USA, Canada, Portugal, Brazil, Chile, South Africa, Egypt, Ghana, Indonesia, Malaysia, India, Russia, Belarus,etc.

....
