High Quality Blister Packing Machine Line
| Specification |
|
This Blister-Cartoner Line is combined with DPH260 Blister Machine and ZH330 Cartoner.
·The line’s maximum output reaches 330cartons/minute, processing of all common solid dose products and all types of forming material.
·Blister module with forming material reels of up to 600mm in diameter can run for 90 minutes of uninterrupted production. ·Capable of all standard types of closure systems for cartons from tuck-in to hot-melt. ·The heart of a Blister Line is the connection between the Blister and Cartoning machine. In this line, the connection phase is truly innovative thanks to the vacuum arms and blister counting magazine that adopt precise servo technology. These accurately control blister transfer, faulty blister rejection, positioning, and feeding, etc., to assure the stability of high running speed. ·The machine can be equipped with an online inspection system, and auto rejection and bar code inspection system. ·Can be connected to subsequent machines, e.g., Stretch- Banding Machine (Overwrapper), Weight Checker, and Case Packer to form whole efficiency production lines. DPH260 Blister Machine's Main Technical Parameters:
Max.Speed: alu/pvc:200punches/min. alu/alu:100punches/min.
Machine Power: 15kw Machine Dimension: 4800x1250x2000mm Machine Weight: 2500kg ZH300 Cartoner's Main Technical Parameters:
Max. Output: 300 cartons/min.
Range of Carton Size: Max.: 160x110x60mm Min.: 55x30x15mm Machine Power: 3kw Machine Dimension: 4500x1620x1600mm Machine Weight: 1200kg |
| Photo |
|
1. Blister module with forming material reels of up to 600mm in diameter can run for 90 minutes of uninterrupted production.
2. Adopts transfer belt to connect the Blister Machine and Cartoner, it provides easy changeover for different sizes of formats and cartons.
3. Inside the magazine, the blister cards are counted when they free fall via the servo-motor, and are then held in position by the transfer belt.
|
| Guarantee & After-selling Service |
|
We will supply enough spare parts and accessories with our machine when shipment. Within one year after receiving our machine, If there are any damaged parts or accessoreis, We will supply them to you by air-mail FREE OF CHARGE.
|
| Certificate |
CE and cGMP |
| About our Company |
|
We are a professional pharmaceutical machinery manufacturer integrating development, production, marketing and service.
We are dedicated and driven to provide the best equipment to meet our customers' requirements that come from pharmaceutical, food, cosmetic and chemical industries. Up to now we have delivered outstanding, innovative and high quality equipment to customers in more than 80 countries around the globe. |
....
