Home > Products > Grinding Machine > Hydraulic Surface grinder machine for sale MY3060
Hydraulic Surface grinder machine for sale MY3060
- 30 Set / Sets per Month
- shenzhen
- T/T D/P D/A Credit Card
You May Like
-
High precision surface grinding machine,Surface Grinder YH-006 With Low Price
-
High precision surface grinding machine, surface grinder YM-7180X16B With Low Price
-
High Precision surface grinding machine price YM-7180X16B
-
High precision surface grinding machine MY7132x20 With Low Price
-
Surface grinder MY7170X16
-
CNC Gantry surface grinding machine YM-K5012
Product Details
| Condition | New | Type | Surface Grinding Machine | |
| CNC or Not | Normal | Max. Grinding Diameter | 320mm | |
| Max. Grinding Length | 630mm | Place of Origin | Guangxi, China | |
| Brand Name | xiashi | Model Number | MY3060 | |
| Voltage | 380v | Power(W) | 3.79kw | |
| Dimension(L*W*H) | 1960*1480*1850 | Weight | 1.3Ton | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Hydraulic surface grinder MY3060
Technical Parameters | Unit | MY3060 | |
piece to be Ground (L×W×H) | mm | 630×310×390 | |
Max. Grinding Length | mm | 630 | |
Max. Grinding width | mm | 320 | |
Distance From Table Surface To Spindle Center | mm | 550 | |
Slide way |
| V-type rail with Steel-ball | |
V-type rail with Stell-ball | Kg | 200 | |
Table Size (L×W) | mm | 600×300 | |
Number of T -Slot | mm×n | 14×1 | |
V-type rail with Steel-ball (Grinding Length/width) | m/min |
| |
Cross Feed On Handwheel | mm | 0.02/Graduation 2.5/revolution | |
Vertical Feed On Handwheel | mm | 0.01Graduation 1.25/revolution | |
Wheel Size (dia×width×bore) | mm | 250×25.4×76.2 | |
Spindle speeds | 50HZ | rpm | 2850 |
| 0-6000 | ||
Totale Power | Kw | 3.79 | |
Spindle Motor | Kw | 2.2 | |
Working Pressure | Mpa | 4 | |
Max. Capacity | L/min | 20 | |
Oil tark capacity | L | 100 | |
Surface Roughness | μm | Ra0.32 | |
Paraller Level | mm | 300:0.005 | |
Machine Size (L×W×H) | mm | 1960×1480×1850 | |
Packing Size (L×W×H) | mm | 2000×1640×2020 | |
Cross,Net | T | 1.43,1.3 | |
Detailed pictures for your reference
If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
