M1080B Centerless Grinder machine
- 30 Set / Sets per Month
- shenzhen
- T/T D/P D/A Credit Card
You May Like
-
High Precision Centerless Grinding Machine MK10200A,Centerless Grinder With Low Price
-
M1040B Centerless Grinder
-
M1050A Centerless Grinder, centerless grinding machine
-
CNC Grinding Machine,Centerless Grinding Machine,Centerless Grinder MK1060 With Low Price
-
Grinding wheel chamfer MR-R500
-
Excellent quality CNC rotor groove grinder machine DHK021
Product Details
| Condition | New | Type | Cylindrical Grinding Machine | |
| CNC or Not | Normal | Max. Grinding Diameter | 5-80mm | |
| Model Number | M1080B | Voltage | 380v | |
| Power(W) | 17kw | Dimension(L*W*H) | 1950*1580*1485mm | |
| Weight | 3500kg | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Features
Structure of fixed grinding wheel and movable regulating wheel
The grinding wheel designed in cantilever type, and its spindle adopted multi-plate
long bearing bushed static-hydrodynamical oil film bearing.
Cantilevered regulating wheel, the spindle supports solid bearing sliding with 1:30
Taper.
The regulating wheel feed slide is supported on roller guideway.
AC frequency converter is used for regulating wheel speed control .
Hydraulic transmission & stepless speed regulation are adopted on regulating wheel
& grinding wheel dresser.
Equipped plunge device in the grinder.
Main Application
The grinder is mainly used for through-feed grinding of cylindrical surface and
ring-type parts, as well as for plunge-cut grinding of various stepped, cones by
manual operation .
Technical parameter
Thru-feed |
|
1)Grinding diameter | 5-80mm |
2)Grinding length | 180mm |
Plunge feed |
|
1)Grinding diameter | 5-80mm |
2)Grinding length | 140mm |
Grinding wheel specifications | P500*150*305mm |
Regulating wheel specifications | PSA300*150*127mm |
Grinding wheel speed | 1300r/min |
Regulating wheel speed(stepless) | 14-180r/min |
Swiveling angle of regulating wheel |
|
1)Invertical plane | -2°~ 5° |
2)In horizontal plane | 0°~ 3° |
Feed amount per division of the feed handwheel | 0.005mm |
Feed amount per division of the dresser | 0.01mm |
Height from centerline of gri.wheel & reg.wheel to workest | 210mm |
Toal power of machine | 17kw |
1)Grinding wheel motor | 15kw |
2)Regulating wheel motor | 1.5kw |
Overall dimensions | 1950*1580*1485mm |
Machine weight | about 3500kg |
Machining accuracy |
|
1)Roundness | 0.002mm |
2)Cylindricity | 0.003mm |
3)Surface Roughness | Ra0.32um |
Detailed pictures for your reference
If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
