Home > Products > Grinding Machine > CNC Gantry Type Surface Grinding Machine YM-K2212
CNC Gantry Type Surface Grinding Machine YM-K2212
- Shenzhen
- T/T Credit Card
You May Like
-
High Precision CNC Grinding Machine,CNC Gantry Surface Grinding Machine YM-K6020 With Low Price
-
YM-K3016 High Quality CNC Grinding Machine, CNC Gantry Surface Grinding Machine With Low Price
-
CNC Gantry Surface Grinding Machine YM-K4020
-
Dependable Performance CNC Grinding Machine,CNC Gantry Surface Grinding Machine YM-K4016 With Low Price
-
YM-K6012 High Quality CNC Gantry Surface Grinding Machine With Low Price
-
YM-K6016 High Quality CNC Grinding Machine, CNC Gantry Surface Grinding Machine With Cheap Price
Product Details
| Condition | New | Type | Surface Grinding Machine | |
| CNC or Not | CNC | Max. Grinding Diameter | 1200 | |
| Max. Grinding Length | 2200mm | Place of Origin | Guangxi, China | |
| Brand Name | Xiashi | Model Number | YM-K2212 | |
| Voltage | 380V | Power(W) | 60kw | |
| Dimension(L*W*H) | 6680MM*3300MM*4160MM | Weight | 22000kg | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
CNC Gantry surface grinding machine YM-K2212
Technical Specification
|
| unit | YM-K2212 | YM-K3012 | YM-K4012 | YM-K5012 | YM-K6012 | ||||||||||||||||
Max.grinding size | Max. Grinding length | mm | 2200 | 3000 | 4000 | 5000 | 6000 | ||||||||||||||||
| Max. Grinding width | mm | 1200 | ||||||||||||||||||||
| Max.grinding height | mm | Standard 830 Optional 1030 | ||||||||||||||||||||
main spindle | kw | 22 | |||||||||||||||||||||
| grinding wheel size | mm | 500*100*203 | |||||||||||||||||||||
| grinding wheel linera speed | m/s | ≤35 | |||||||||||||||||||||
| load of worktable | 1500kg/lin.m | ||||||||||||||||||||||
| processing area | mm | 2200*1200 | |||||||||||||||||||||
| processing travel | mm | 2200 | |||||||||||||||||||||
| max travel | mm | 2600 | |||||||||||||||||||||
| max movement of grinding head | m/min | 6 | |||||||||||||||||||||
| feeding amout of grinding head | mm | 0-40 | |||||||||||||||||||||
| dimension | mm | 6680*3300*4160 | |||||||||||||||||||||
| machine weight | kg | 22000 | |||||||||||||||||||||
Picture for your reference
Packing&Delivery&Terms of Payment
We use wooden package to protect the equipment in container.
Why Choose Us?
- We have our own factory and strong production capacity.
- we insist on good quality and have strict quality standards
- The hiring of experienced staff to guarantee high quality.
- Our product can be made as per your requirement .
- 24 hour online communication for you.
- We have more than 6 years of export experience.
FAQ
Q: What information should I let you know, if I want to get a product offer?
A: 1. the size of your work piece
2. the CNC system you preferred if you need CNC type
3. the work piece drawing if you have
Q: How to control the quality of production processes?
A: We have a professional quality inspectors to check on the quality of the finished product.
Q: Is it possible to visit your factory?
A: It is very convenient to visit us and all clients from around the world are highly welcomed.
Q: What’s the MOQ?
A: The MOQ is 1 set.
Q: What’s the quality assurance and service ?
A: We offer one year warranty and 100% quality inspection before shipment. We shall reply your message within 24 hours to solve your problem.
