Home > Manufacturing & Processing Machinery > Machine Tools > Grinding Machine > Centerless Grinder M1010B Grinding Machine

Centerless Grinder M1010B Grinding Machine

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Cylindrical Grinding Machine

CNC or Not:

Normal

Contact Supplier Request Quote Chat Now

Guangxi Xiashi Machinery Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Cylindrical Grinding Machine

CNC or Not Normal

Max. Grinding Diameter 10-200mm

Model Number M1010B

Voltage 380v

Power(W) 2.31kw

Dimension(L*W*H) 1125*1125*1500mm

Weight about850kg

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Salient features

Structure of fixed grinding wheel and movable regulating wheel

The grinding wheel designed in cantilever type, and its spindle adopted multi-plate long bearing bushed static-hydrodynamical oil film bearing.

Cantilevered regulating wheel, the spindle supports solid bearing sliding with 1:30 taper.

The swallow tailed roller guideway & differential screw supports the regulating wheel feeding

AC frequency converter is used for regulating wheel speed control .

Hydraulic transmission & stepless speed regulation are adopted on regulating wheel & grinding wheel dresser.

Equipped automatic plunge device in the grinder.

Main Application
The grinder is mainly used for through-feed grinding of cylindrical surface and ring-type parts, as well as for plunge-cut grinding of various stepped, cones by manual operation .

Technical parameter

Thru-feed
1)Grinding diameter	0.5-10mm
2)Grinding length	40mm
Plunge feed
1)Grinding diameter	3-10mm
2)Grinding length	40mm
Grinding wheel specifications	P2005075mm
Regulating wheel specifications	P1255050mm
Grinding wheel speed	3320r/min
Regulating wheel speed(stepless)	45-240r/min
Swiveling angle of regulating wheel
1)Invertical plane	-2°~ 5°
2)In horizontal plane	0°~ 3°
Feed amount per division of the feed handwheel	0.001mm
Feed amount per division of the dresser	0.02mm
Height from centerline of gri.wheel & reg.wheel to workest	125mm
Toal power of machine	2.31kw
1)Grinding wheel motor	1.5kw
2)Regulating wheel motor	0.6kw
Overall dimensions	112511251500mm
Machine weight	about 850kg
Machining accuracy
1)Roundness	0.002mm
2)Cylindricity	0.003mm
3)Surface Roughness	Ra0.32um

Detailed pictures for your reference

If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
