Good Automactic Soft Drink Filling Line Manufacturer

Good Automactic Soft Drink Filling Line Manufacturer thumbnail-1
Good Automactic Soft Drink Filling Line Manufacturer thumbnail-2
Good Automactic Soft Drink Filling Line Manufacturer thumbnail-3
Good Automactic Soft Drink Filling Line Manufacturer thumbnail-4
Good Automactic Soft Drink Filling Line Manufacturer photo-1
Good Automactic Soft Drink Filling Line Manufacturer photo-2
Good Automactic Soft Drink Filling Line Manufacturer photo-3
Good Automactic Soft Drink Filling Line Manufacturer photo-4
US$ 15,000 - 35,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Primary Ingredient:
Dietary Fibre
Flavor:
Fruity
Feature:
Low-Carb
Contact Supplier Request Quote Chat Now
Zhangjiagang Jiazhou Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai for soft drink filling line manufacturer
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Primary Ingredient Dietary Fibre
Flavor Fruity
Feature Low-Carb
Color gray
Certification ISO
Packaging Bottle
Shelf Life 1 year
Place of Origin Jiangsu, China
Brand Name JZ
Model Number CGFD

P/roduct information Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description Good automactic soft drink filling line manufacturer

1.The plastic bottles are fed into the rotary rinser,filler capper by means of an input feed air conveyor.

2.A star wheel then transfers the bottle to neck holding gripper of the rinsing station.

3.The rinsing robot indexes the bottle 180°and activates the rinsing value.Bottles after being rinsed are automatically transferred by a star wheel to the filling station.

4.In the filling station the bottles are picked up by the neck, allocated individual filling values and sealed by rubber, Next a valve opens to inject CO2 while simultaneously a second vent(bleed) valve is opened to displace the prviously oxygenated air from the container.

5.Once eventually all of the oxygen has been replaced by CO2 the vent is closed and another valve opens to let the product flows into the container down the wall of bottle.

6.After filling is complete a vent is opend to allow excess product to escape which defines the classic liquid leve fill that you see in all carboanted drinks.

7.Finally the filled container is ready for sealing and the faster the better. Bottled carbonated drinks can go directly to capping station without much worry as the foam caused by escaping CO2 denies atomopheric oxygen from entering the product.

8.The state-of-art filling valve is so precise and accurate it gives even filling in all bottles.The filled bottles are then transferred to the capping station via a star wheel.The bottles automatically move for the capping stage where the caps release from the sorter on to the bottles.The caps are sealed automatically using special capping hands.

9.The entire system is enclosed in a stainless steel/glass outer casing.

10.After the capping stage the bottle are automatically ejected out to the out feed conveyor.

11.The whole equipment is sleek and is capable of bottling various sizes of PET bottles ranging from 250 ml to 2 ltrs.

Product display Good automactic soft drink filling line manufacturer



Good automactic soft drink filling line manufacturer



Good automactic soft drink filling line manufacturer

Product Parameters Good automactic soft drink filling line manufacturer
Model DCGF
18186		 DCGF
24248		 DCGF
323212		 DCGF
404015		 DCGF
505018		 DCGF
606020
Head of washing, filling, sealing 18-18-6 24-24-8 32-32-8 40-40-10 50-50-18 60-60-20
Production capacity (bottle/hour)   3000-4000 5000-6000 7000-8000 9000-10000 11000-12000 15000
Suitable bottle diameter(mm) φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100  H=150-310  330-1500ml
Filling precision ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm
Motor power 3.84kw 4.1kw 5.6kw 7.5kw 9kw 11kw
Filling pressure ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4
Overall dimension     (mm) 2400×1900
×2300		 2800×2100
×2300		 4200×2300
×2300		 5000×2800
×2400		 5900×3100
×2400		 6500×3500
×2400
Weight(Kg) 3000 4000 5000 7500 9000 11000
Good automactic soft drink filling line manufacturer
C/ompany information Zhangjiagang Jiazhou Machinery Co., Ltd.
Good automactic soft drink filling line manufacturer
O/ur advantage Zhangjiagang Jiazhou Machinery Co., Ltd.
Good automactic soft drink filling line manufacturer
O/ur certificate Zhangjiagang Jiazhou Machinery Co., Ltd.
Good automactic soft drink filling line manufacturer
N/etwork Marketing Zhangjiagang Jiazhou Machinery Co., Ltd.
Good automactic soft drink filling line manufacturer
P/ackaging & shipping Zhangjiagang Jiazhou Machinery Co., Ltd.
WGood automactic soft drink filling line manufacturerWelcome to Zhangjiagang Jiazhou Machinery Co., Ltd.
