Full automatic carbonated soft drink filling machine (Hot sale)
We supply full automatic carbonated soft drink filling machine.
We supply complete carbonated soft drink production line (for 15years). It is plastic bottle packaging line. We have 1000-2000bottles/hour, 3000-4000bottles/hour, 5000bottles/h, 10000bottles/hour and so on, which capacity would you prefer?
Please mail us below and I will send quotation with detailed pictures & technical data to your email. thank you!
Complete carbonated drinks production line include water treatment system, sugar melting tank, flavour blending tank, Co2 drink mixer, water chiller, bottle filling and packing system and so on.
Main equipments as below:
1. Water treatment system (quartz sand filter, active carbon filter, softner, RO system and so on)
2. Ozone generator sterilizer
3. Aseptic water storage tank
4. Sugar melting tank & syrup filter
5. Flavour blending tank & syrup cooler
6. Co2 drink mixer & Co2 filter
7. Water chiller
8. Auto bottle washing, filling and capping line
9. Labeling machine
10. Date of manufacture printer
11. Final products film packaging machine and so on.
conveyor
1 washing part
2 filling machine
3 capping machine
Automatic 3 in 1 water soft drink liquid filling machine
Main technical standards:
Model |
DCGF18186 |
DCGF24248 |
DCGF323212 |
DCGF404015 |
DCGF505018 |
DCGF606020 |
Head of washing, filling, sealing |
18-18-6 |
24-24-8 |
32-32-8 |
40-40-10 |
50-50-18 |
60-60-20 |
Production capacity (bottle/hour) |
3000-4000 |
5000-6000 |
7000-8000 |
9000-10000 |
11000-12000 |
15000 |
Suitable bottle diameter(mm) |
φ=50-100 H=150-310 330-1500ml |
φ=50-100 H=150-310 330-1500ml |
φ=50-100 H=150-310 330-1500ml |
φ=50-100 H=150-310 330-1500ml |
φ=50-100 H=150-310 330-1500ml |
φ=50-100 H=150-310 330-1500ml |
Filling precision |
≤±5mm |
≤±5mm |
≤±5mm |
≤±5mm |
≤±5mm |
≤±5mm |
Motor power |
3.84kw |
4.1kw |
5.6kw |
7.5kw |
9kw |
11kw |
Filling pressure |
≤0.4 |
≤0.4 |
≤0.4 |
≤0.4 |
≤0.4 |
≤0.4 |
Overall dimension (mm) |
2400×1900×2300 |
2800×2100×2300 |
4200×2300×2300 |
5000×2800×2400 |
5900×3100×2400 |
6500×3500×2400 |
Weight(Kg) |
3000 |
4000 |
5000 |
7500 |
9000 |
11000 |
