carbonated drinks filling machine
The Carbonated Beverage filling machine combines washing, filling and rotary capping functions in one unit, is a fully automatic and high efficieney liquid packing equipment.
The Carbonated Beverage filling machine is suitable for packing beverage cintaining gas. Its performance is as following: All parts, for instance, filling value, which directly contact medium are made of stainless steel. So conform to the requirements of Food sanitation. Sealing parts are made of heat-proofing rubber, in order to meet the techique requirement of users to sterilize the whole machine at high temperature. Using programmable controller to realize fully zutomatic control from bottles entering to finishing packing. Using transducer as speed regulator, so the user can regulate the machine easily to suit different power requirements. Adopting balanced pressure filling principle and spring valvers in order to assure beverage quality. Using advanced magnetic coupler to regulate cap-screwing torque, in order to assure capping quelity.
| Model | CGFD16126 | CGFD18186 | CGFD24248 | CGFD32328 | CGFD404010 | CGFD505012 | CGFD 606015 | CGFD808020 |
| Filler/Capper heads | 16-12-6 | 18-18-6 | 24-24-8 | 32-32-8 | 40-40-10 | 50-50-12 | 60-60-15 | 80-80-20 |
| Bottle diameter(mm) | φ=50-100 H=170 330-1500ML | φ=50-110 H=160-340 | ||||||
| Production capacity(350ml)(b/h) | 2000-4000 | 4000-6000 | 8000-10000 | 10000-12500 | 12500-15000 | 16000-20000 | 20000-24000 | 26000-32000 |
| Filling temperature ºC | 0-5 | |||||||
| Filler type | Balanced pressure filler | |||||||
| Spraying pressure(Mpa) | 0.2-0.25 | |||||||
| Filling pressure(Mpa) | 0.15-0.35 | 0.2-0.4 | ||||||
| Motor power(kw) | 2.2+0.55+0.12 | 2.2+0.55+0.18 | 3+0.55+0.18 | 5.5+0.55+0.18 | 7.5 | 11 | 15 | 19 |
| Overall dimension (L*W*H)mm | 2300*1600*2500 | 2600*1920*2550 | 3100*2200*2800 | 3850*3000*2850 | 4850*3800*2750 | 5750*3550*2750 | 6500*5500*2750 | 7680*6640*2650 |
| Weight(kg) | 2800 | 3650 | 4800 | 6800 | 8650 | 10500 | 12800 | 15000 |
