Good quality beverage filling plant price

FOB Price

USD $5,000 - $11,000 / Unit

1 Unit(Min.Order)

Product Details

Condition:	New	Application:	Beverage, Other, Beverage, Carbonated Drink	Packaging Type:	Bottles
Packaging Material:	Plastic	Automatic Grade:	Automatic	Driven Type:	Pneumatic
Voltage:	220V	Power:	2.2KW	Place of Origin:	Jiangsu, China
Brand Name:	JZ	Model Number:	DCGF	Dimension(LWH):	280024002900mm
Weight:	2T	Certification:	CEISO	After-sales Service Provided:	Engineers available to service machinery overseas

P/roduct information

Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description

1. Not only can it be connected CIP cleaning system, PLC control and touch screen system

2.Equipped with the Air-purifying system

3.Safety device: safeguard switch

4.Some functions can be added or removed according to the customers’ requirement

5.This machine is suitable for packing jelly, soy milk, yoghourt, mineral water, juice, ice cream, edible oil, seasoning, scour and so on

6.Specially suitable for stang up spout pouch filing and capping

7.Capping is applying magnetic adjusting torque for rather stability

Product display

Product Parameters

Model	DCGF 18186	DCGF 24248	DCGF 323212	DCGF 404015	DCGF 505018	DCGF 606020
Head of washing, filling, sealing	18-18-6	24-24-8	32-32-8	40-40-10	50-50-18	60-60-20
Production capacity (bottle/hour)	3000-4000	5000-6000	7000-8000	9000-10000	11000-12000	15000
Suitable bottle diameter(mm)	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml
Filling precision	≤±5mm	≤±5mm	≤±5mm	≤±5mm	≤±5mm	≤±5mm
Motor power	3.84kw	4.1kw	5.6kw	7.5kw	9kw	11kw
Filling pressure	≤0.4	≤0.4	≤0.4	≤0.4	≤0.4	≤0.4
Overall dimension (mm)	2400×1900 ×2300	2800×2100 ×2300	4200×2300 ×2300	5000×2800 ×2400	5900×3100 ×2400	6500×3500 ×2400
Weight(Kg)	3000	4000	5000	7500	9000	11000

C/ompany information	Zhangjiagang Jiazhou Machinery Co., Ltd.

O/ur certificate	Zhangjiagang Jiazhou Machinery Co., Ltd.

C/ontact us	Zhangjiagang Jiazhou Machinery Co., Ltd.

Zhangjiagang Jiazhou Machinery Co., Ltd.: Contact nameLinda Zhu; Phone86-512-58531610; AddressSanxing Development Zone, Jinfeng Town, Zhangjiagang
