Great Soft Drinks Beverage Production Line

US$ 8,000 - 10,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Application:

Beverage, Other, Beverage, Carbonated Drink

Packaging Type:

Bottles

Zhangjiagang Jiazhou Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shanghai for beverage production line

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Beverage, Other, Beverage, Carbonated Drink

Packaging Type Bottles

Packaging Material Plastic

Automatic Grade Automatic

Driven Type Pneumatic

Voltage 220V

Power 2.2KW

Place of Origin Jiangsu, China

Brand Name JZ

Model Number DCGF

Dimension(L*W*H) 2200*13002400mm

Weight 1.8T

Certification CE ISO

After-sales Service Provided Engineers available to service machinery overseas

P/roduct information

Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description

FEATURES

The air conveyor is directly connected with bottle inlet starwheel. The bottles are transferred by neck holding.
High speed filling line is of clamping transferring technology. Bottle shapes are more varied, and the working table inside the machine is more laconic.
By 3-in-1 monoblock, the bottle goes through rinsing, filling and capping with little abrasion, and the transferring is stable, bottle changing is easier.
Specially designed stainless steel bottle clamps don't contact the thread parts of the bottle neck, avoiding the second contamination.
The high speed line is of ring type pressure bearing hydraulic cylinder.
High speed and large flow filling valve assures the high filling speed and exact fluid level.
Liquid contact parts are all of excellent stainless steel or food level rubber. The electrical parts and pneumatic components are of international brand and achieve the national food sanitary standard. Such as PLC from OMRON or SIEMENS, motors from SEW, pneumatic components from SMC or AIRTAC, etc.
The bottle outlet starwheel is of screwdown shape. When bottle size is changed, there is no need to adjust the transferring chain’s height.

Product display

Product Parameters

Model	DCGF 18186	DCGF 24248	DCGF 323212	DCGF 404015	DCGF 505018	DCGF 606020
Head of washing, filling, sealing	18-18-6	24-24-8	32-32-8	40-40-10	50-50-18	60-60-20
Production capacity (bottle/hour)	3000-4000	5000-6000	7000-8000	9000-10000	11000-12000	15000
Suitable bottle diameter(mm)	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml
Filling precision	≤±5mm	≤±5mm	≤±5mm	≤±5mm	≤±5mm	≤±5mm
Motor power	3.84kw	4.1kw	5.6kw	7.5kw	9kw	11kw
Filling pressure	≤0.4	≤0.4	≤0.4	≤0.4	≤0.4	≤0.4
Overall dimension (mm)	2400×1900 ×2300	2800×2100 ×2300	4200×2300 ×2300	5000×2800 ×2400	5900×3100 ×2400	6500×3500 ×2400
Weight(Kg)	3000	4000	5000	7500	9000	11000
