carbonated drink bottling machine
- 15 Set / Sets per Month
- T/T
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Application: | Beverage | Packaging Type: | Bottles | ||
Packaging Material: | Plastic | Automatic Grade: | Other, Automatic, Automatic | Driven Type: | Other, Pneumatic, Electric |
Power: | 3.0kw | Place of Origin: | Jiangsu, China | Brand Name: | JIAZHOU |
Model Number: | DCGF-18186 |
Product Description
bottling machine
Product Description
The series carbonated monobloc filling machine is used in production of PET bottle-packing carbonated beverage such as mineral water, pure water etc no gas containing beverage with the capacity from 3000-20000B/H
Technical parameter
Model: DCGF18186
Production capacity: 4000-5000b/h (basis on 500ml bottle)
Filling precision: ≤±5mm (liquid level)
Filling pressure: 0.4Mpa
Polyester bottle specification: bottle diameter:φ50-φ100mm
bottle height: 150-320mm
suitable cap type: plastic screw cap
water pressure of washing bottle: 0.18-0.25Mpa
water consumption for washing bottle: 2000kg/h
air source pressure: 0.4Mpa
air consumption: 0.4m3/min
total power: 3.0kw
overall dimension: 2450×1800×2200mm
