Automatic Soft Drink or Carbonated Drink Filling Machine Price

Automatic Soft Drink or Carbonated Drink Filling Machine Price photo-1
Automatic Soft Drink or Carbonated Drink Filling Machine Price photo-2
US$ 1,000 - 15,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Water
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai fro carbonated drink filling machine price
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Water
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220V
Power 2.2KW
Place of Origin Jiangsu, China
Brand Name JZ
Model Number DCGF
Dimension(L*W*H) 2800*2500*2900mm
Weight 2T
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

P/roduct information Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description Automatic Soft drink or carbonated drink filling machine price
We supply full automatic carbonated soft drink filling machine.
We supply complete carbonated soft drink production line (for 15years). It is plastic bottle packaging line. We have
1000-2000bottles/hour, 3000-4000bottles/hour, 5000bottles/h, 10000bottles/hour and so on, which capacity would
you prefer?
Please mail us below and I will send quotation with detailed pictures & technical data to your email. thank you!

Complete carbonated drinks production line include water treatment system, sugar melting tank, flavour blending tank,
Co2 drink mixer, water chiller, bottle filling and packing system and so on.

Main equipments as below:
1. Water treatment system (quartz sand filter, active carbon filter, softner, RO system and so on)
2. Ozone generator sterilizer
3. Aseptic water storage tank
4. Sugar melting tank & syrup filter
5. Flavour blending tank & syrup cooler
6. Co2 drink mixer & Co2 filter
7. Water chiller
8. Auto bottle washing, filling and capping line
9. Labeling machine
10. Date of manufacture printer
11. Final products film packaging machine and so on.
Product display Automatic Soft drink or carbonated drink filling machine price
Automatic Soft drink or carbonated drink filling machine price
Product Parameters Automatic Soft drink or carbonated drink filling machine price
Model DCGF
18186
DCGF
24248
DCGF
323212
DCGF
404015
DCGF
505018
DCGF
606020
Head of washing, filling, sealing 18-18-6 24-24-8 32-32-8 40-40-10 50-50-18 60-60-20
Production capacity (bottle/hour)   3000-4000 5000-6000 7000-8000 9000-10000 11000-12000 15000
Suitable bottle diameter(mm) φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100  H=150-310  330-1500ml
Filling precision ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm
Motor power 3.84kw 4.1kw 5.6kw 7.5kw 9kw 11kw
Filling pressure ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4
Overall dimension     (mm) 2400×1900
×2300
2800×2100
×2300
4200×2300
×2300
5000×2800
×2400
5900×3100
×2400
6500×3500
×2400
Weight(Kg) 3000 4000 5000 7500 9000 11000
Automatic Soft drink or carbonated drink filling machine price
C/ompany information Zhangjiagang Jiazhou Machinery Co., Ltd.
Automatic Soft drink or carbonated drink filling machine price
O/ur advantage Zhangjiagang Jiazhou Machinery Co., Ltd.
Automatic Soft drink or carbonated drink filling machine price
O/ur certificate Zhangjiagang Jiazhou Machinery Co., Ltd.
Automatic Soft drink or carbonated drink filling machine price
N/etwork Marketing Zhangjiagang Jiazhou Machinery Co., Ltd.
Automatic Soft drink or carbonated drink filling machine price
P/ackaging & shipping Zhangjiagang Jiazhou Machinery Co., Ltd.
Automatic Soft drink or carbonated drink filling machine price
C/ontact us Zhangjiagang Jiazhou Machinery Co., Ltd.
Automatic Soft drink or carbonated drink filling machine price
