Best Price Carbonated Soft Drink Production Line

Best Price Carbonated Soft Drink Production Line thumbnail-1
Best Price Carbonated Soft Drink Production Line thumbnail-2
Best Price Carbonated Soft Drink Production Line thumbnail-3
Best Price Carbonated Soft Drink Production Line thumbnail-4
Best Price Carbonated Soft Drink Production Line photo-1
Best Price Carbonated Soft Drink Production Line photo-2
Best Price Carbonated Soft Drink Production Line photo-3
Best Price Carbonated Soft Drink Production Line photo-4
US$ 9,000 - 22,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Other, Beverage, Carbonated Drink
Packaging Type:
Bottles
Contact Supplier Request Quote Chat Now
Zhangjiagang Jiazhou Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai for carbonated soft drink production line
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Beverage, Other, Beverage, Carbonated Drink
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220V
Power 2.2KW
Place of Origin Jiangsu, China
Brand Name JZ
Model Number DCGF
Dimension(L*W*H) 2300*1500*2500mm
Weight 2.3T
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

P/roduct information Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description Best price carbonated soft drink production line

Product introduction:

This machine has washer,filler,capper three functions in one body, automatic in total process, it is suitable for PET bottled cola ,sprint etc. It makes by high quality SUS304, key parts are precision machined by NC tool. The total machine uses advanced photoelectric detection technology to detect each part’s operation status, no bottle no filling, and no bottle no capping, automatic and easy operation.

Main features of the equipments:

1)Using the wind sent access, with clamp hanging the bottle neck ; which can keep the bottle shape and high-speed.

2)Washing bottle mouth with special designed washing manipulator,clip in the bottle neck, stable and avoid secondary pollution.

3)The cylinder drives the valve, correct and reliable, high speed flow rate, high precision filling valve, CIP loop.

4)Capping adopts French advanced technology, cap sorter install in a lower position, send cap in level position.

5)Host adopts advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.

Product display Best price carbonated soft drink production line

Best price carbonated soft drink production line



Best price carbonated soft drink production line



Best price carbonated soft drink production line

Product Parameters Best price carbonated soft drink production line
Model DCGF
18186		 DCGF
24248		 DCGF
323212		 DCGF
404015		 DCGF
505018		 DCGF
606020
Head of washing, filling, sealing 18-18-6 24-24-8 32-32-8 40-40-10 50-50-18 60-60-20
Production capacity (bottle/hour)   3000-4000 5000-6000 7000-8000 9000-10000 11000-12000 15000
Suitable bottle diameter(mm) φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100  H=150-310  330-1500ml
Filling precision ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm
Motor power 3.84kw 4.1kw 5.6kw 7.5kw 9kw 11kw
Filling pressure ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4
Overall dimension     (mm) 2400×1900
×2300		 2800×2100
×2300		 4200×2300
×2300		 5000×2800
×2400		 5900×3100
×2400		 6500×3500
×2400
Weight(Kg) 3000 4000 5000 7500 9000 11000
Best price carbonated soft drink production line
C/ompany information Zhangjiagang Jiazhou Machinery Co., Ltd.
Best price carbonated soft drink production line

O/ur certificate Zhangjiagang Jiazhou Machinery Co., Ltd.
Best price carbonated soft drink production line


C/ontact us Zhangjiagang Jiazhou Machinery Co., Ltd.
Best price carbonated soft drink production line
