Small Capacity Carbonated Soft Drink Filling Machine Manufacturer

Small Capacity Carbonated Soft Drink Filling Machine Manufacturer thumbnail-1
Small Capacity Carbonated Soft Drink Filling Machine Manufacturer thumbnail-2
Small Capacity Carbonated Soft Drink Filling Machine Manufacturer thumbnail-3
Small Capacity Carbonated Soft Drink Filling Machine Manufacturer thumbnail-4
Small Capacity Carbonated Soft Drink Filling Machine Manufacturer photo-1
Small Capacity Carbonated Soft Drink Filling Machine Manufacturer photo-2
Small Capacity Carbonated Soft Drink Filling Machine Manufacturer photo-3
Small Capacity Carbonated Soft Drink Filling Machine Manufacturer photo-4
US$ 20,000 - 30,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Other, Beverage, Carbonated Drink
Packaging Type:
Bottles
Contact Supplier Request Quote Chat Now
Zhangjiagang Jiazhou Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai for soft drink filling machine
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Beverage, Other, Beverage, Carbonated Drink
Packaging Type Bottles
Packaging Material Wood
Automatic Grade Automatic
Driven Type Pneumatic
Voltage 220V
Power 2.2KW
Place of Origin Jiangsu, China
Brand Name JZ
Model Number CGFD
Dimension(L*W*H) 3500*1800*2500mm
Weight 3T
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

P/roduct information Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description Small capacity carbonated soft drink filling machine manufacturer

Soft Drink Filling Machine -Characteristics

1.This kind of  soft drink filling machine  combines washing,filling and rotary capping functions  in one unit.It is a fully automatic and high efficiency liquid packing equipment.

2.  soft drink filling machine is suitable for packing beverage containing gas.  soft drink filling machine 's performance is as following all parts,for instance, filling valve, which directly contact medium are made of stainless steel or harmless material. So it conforms to the requirements of Food sanitation. Sealing parts are made of heat-proofing rubber, in order to meet the technique requirements of users to sterilization at high temperature.

3.  soft drink filling machine Using programmable controller to realize fully automatic control from bottles entering to finishing packing, soft drink filling machine Using transducer as speed regulator, so the user can regulate the machine easily to suit different power requirements, Adopting equal pressure filling principle and current spring valves in order to assure beverage quality, Using advanced magnetic coupler to regulate cap-screwing torque, in order to assure capping quality.

Product display Small capacity carbonated soft drink filling machine manufacturer

Small capacity carbonated soft drink filling machine manufacturer



Small capacity carbonated soft drink filling machine manufacturer



Small capacity carbonated soft drink filling machine manufacturer

Product Parameters Small capacity carbonated soft drink filling machine manufacturer
Model DCGF
18186		 DCGF
24248		 DCGF
323212		 DCGF
404015		 DCGF
505018		 DCGF
606020
Head of washing, filling, sealing 18-18-6 24-24-8 32-32-8 40-40-10 50-50-18 60-60-20
Production capacity (bottle/hour)   3000-4000 5000-6000 7000-8000 9000-10000 11000-12000 15000
Suitable bottle diameter(mm) φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100  H=150-310  330-1500ml
Filling precision ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm
Motor power 3.84kw 4.1kw 5.6kw 7.5kw 9kw 11kw
Filling pressure ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4
Overall dimension     (mm) 2400×1900
×2300		 2800×2100
×2300		 4200×2300
×2300		 5000×2800
×2400		 5900×3100
×2400		 6500×3500
×2400
Weight(Kg) 3000 4000 5000 7500 9000 11000
Small capacity carbonated soft drink filling machine manufacturer
C/ompany information Zhangjiagang Jiazhou Machinery Co., Ltd.
Small capacity carbonated soft drink filling machine manufacturer
O/ur advantage Zhangjiagang Jiazhou Machinery Co., Ltd.
Small capacity carbonated soft drink filling machine manufacturer
O/ur certificate Zhangjiagang Jiazhou Machinery Co., Ltd.
Small capacity carbonated soft drink filling machine manufacturer
N/etwork Marketing Zhangjiagang Jiazhou Machinery Co., Ltd.
Small capacity carbonated soft drink filling machine manufacturer
P/ackaging & shipping Zhangjiagang Jiazhou Machinery Co., Ltd.

Small capacity carbonated soft drink filling machine manufacturer
