Mineral Water Washing Filling Capping Machine
The equipment completes the washing filling sealing of pure water, mineral water in one machine. The machine design shortens the time of the drink material contacting with the substance outside, and increases the sanitation condition and economic benefit.
It can carry out bottle washing filling and capping in one machine.
The whole machine designing is reasonable, beautiful in appearance and the maintenance is convenient.
It adopts hanging type conveying-bottle structure to make changing bottle model more convenient, faster and easier.
The main machine adopts advanced PLC control technology. The key electric elements are adopting international famous products.
Mineral Water Washing Filling Capping Machine's Main Technic Data
Model | CGF16126 | CGF18186 | CGF24248 | CGF323210 |
Heads of washing, filling, sealing | 16-12-6 | 18-18-6 | 24-24-8 | 32-32-10 |
Production capacity | 3000-4000BPH | 4000-6000 | 8000-10000 | 12000-15000 |
Suitable bottle diameter | Φ=50-100mm, H=170mm, 330-2500ml | Φ=50-100mm, H=170mm, 330-2500ml | Φ=50-100mm, H=170mm, 330-2500ml | Φ=50-100mm, H=170mm, 330-2500ml |
Spraying pressure | 0.2-0.25Mpa | 0.2-0.25Mpa | 0.2-0.25Mpa ³ | 0.2-0.25Mpa |
Motor power | 4.23kw | 5.03kw | 6.57kw | 8.63kw |
Stainless steel | SS304 | SS304 | SS304 | SS304 |
Electric voltage | 380V50Hz | 380V50Hz | 380V50Hz | 380V50Hz |
PLC | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi |
Frequency converters | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi |
Touch screen | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi |
Circuit contactor | Siemens | Siemens | Siemens | Siemens |
Overall dimension (mm) | 2100*1500*2200 | 2450*1800*2200 | 2750*2180*2200 | 3500*2200*2250 |
Weight | 2000kg | 3500kg | 5500kg | 8000kg |
Mineral Water Washing Filling Capping Machine's Washing Part
Mineral Water Washing Filling Capping Machine's Filling Part
Mineral Water Washing Filling Capping Machine's Capping Part
JIAZHOU'S Factory and Workshop
JIAZHOU'S Office
JIAZHOU'S Certificates
JIAZHOU'S Transportation and Packaging
