bottle water filling machine
This Full Automatic bottle filling machine with following specification:
1.Applicable bottle type plastic bottle. PET bottle (the customer offers the sample).
Diameter: ¢50-¢80mm
Height: 160-320mm
2.Applicable cap type plastic cap, metal cap (the customer offer the sample)
3. Method of changing speed: frequency conversion
4.Power of unscramble motor 0.37Kw
5.Supply pressure of rinsing water: >0.06Mpa<0.2Mpa
Technical features and pictures :
Overturning mechanism of bottle washing machine
It mainly composes of bottle washing clamp, upper rotary plate, guide rail, water distributing plate, shield, water spraying device, water tray etc.
Bottle washing clamp rotates with the upper rotary plate, and open the bottle mouth clamp with elastic distortion when contacting the bottle feeding starwheel, which can clamp the bottle neck, then overturns at 180° along the guide rail, bottle mouth may become downwards for cleaning and drying the bottle with water, then overturn for 180°, bottle mouth becomes upwards and then conveyed with the starwheel; shield can prevent sprinkling of cleaning water; water distributing plate can deliver the cleaning water from the still parts to the rotary parts.
