Small Capacity Good Drink Water Manufacturing Machine

Small Capacity Good Drink Water Manufacturing Machine photo-1
Small Capacity Good Drink Water Manufacturing Machine photo-2
Small Capacity Good Drink Water Manufacturing Machine photo-3
Small Capacity Good Drink Water Manufacturing Machine photo-4
US$ 1,000 - 8,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, water, Drinking Water
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai for drink water manufacturing machine
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, water, Drinking Water
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220V
Power 2.2KW
Place of Origin Jiangsu, China
Brand Name JZ
Model Number CGF
Dimension(L*W*H) 2800*2700*2900mm
Weight 2T`
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

P/roduct informationZhangjiagang Jiazhou Machinery Co., Ltd.

Product descriptionSmall capacity good drink water manufacturing machine

Products introduction

This Automatic Pure / Mineral / Drinking Water Filling Machine is used to produce polyester bottled mineral water, purified water, alcoholic beverage machinery and other non-gas beverage machinery.Beverage Machinery can finish all the process such as washing bottle, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency.

Characteristics

1,This drinking water filling equipment adopts bottle neck holding transmission technology to realize fully automatic rinsing,filling and capping.

2,All the electrical elements use international famous brand products.

3,The parts which contact with the beverage are made of high quality stainless steel          SUS304.

4,It adopts human-machine interface touch-screen and PLC program control.

5,It has automatic trouble protected decice.

6,Our machine have the advantage of durable using,high stability,low failure,etc.

Product displaySmall capacity good drink water manufacturing machine

Small capacity good drink water manufacturing machine



Small capacity good drink water manufacturing machine

Product ParametersSmall capacity good drink water manufacturing machine
ModelCGF
18186
CGF
24248
CGF
323212
CGF
404015
CGF
505018
CGF
606020
Head of washing, filling, sealing18-18-624-24-832-32-840-40-1050-50-1860-60-20
Production capacity (bottle/hour)  3000-40005000-60007000-80009000-1000011000-1200015000
Suitable bottle diameter(mm)φ=50-100 H=150-310 330-1500mlφ=50-100 H=150-310 330-1500mlφ=50-100 H=150-310  330-1500mlφ=50-100 H=150-310  330-1500mlφ=50-100 H=150-310  330-1500mlφ=50-100  H=150-310  330-1500ml
Filling precision≤±5mm≤±5mm≤±5mm≤±5mm≤±5mm≤±5mm
Motor power3.84kw4.1kw5.6kw7.5kw9kw11kw
Filling pressure≤0.4≤0.4≤0.4≤0.4≤0.4≤0.4
Overall dimension     (mm)2400×1900
×2300
2800×2100
×2300
4200×2300
×2300
5000×2800
×2400
5900×3100
×2400
6500×3500
×2400
Weight(Kg)3000400050007500900011000

Small capacity good drink water manufacturing machine
