Low Offer Cut 40 Portable Mosfet Type dc Inverter Air Plasma Cutter With CE,CCC

Name: Low Offer Cut 40 Portable Mosfet Type dc Inverter Air Plasma Cutter With CE,CCC
Brand: ANDELI
Availability: InStock

FOB Price

US$ 1 - 160 / Set

1 Set(Min. Order)

Port Ningbo/Shanghai China
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Zhejiang, China
Brand Name	ANDELI	Model Number	CUT 40
Arc Current	230A	Pulse Frequency	50/60HZ
Pilot Arc Current	20~40A	Rated Duty Cycle	60%
Motor Type	DC Motor	Dimensions	400x163x290MM
Usage	DC Air Plasma for Aluminum,Copper and etc	Voltage	single phase AC 220±10% V
Power(W)	6.6KVA	Certification	CE,CCC,ISO9001
Warranty	2 Years	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Low offer Cut 40 Portable Mosfet type dc inverter air plasma cutter with CE,CCC

Why choose us?

1. 20 years - Andeli Group Co.,Ltd is founded in 1993.
2. 12 share holding companies - Andeli have owns 12 share holding companies in Shanghai, Hunan, Zhejiang, UAE.
3. 300 cooperating companies - We have over 300 cooperating companies.
4. 3000 workers - We have over 3000 workers.
5. USD150,000,000 - The total assets is USD150,000,000.
6. 235,000 square meters - The area of Andeli is 235,000 square meters.
7. Certification - We have passed ISO9001:2000 Quality Management System and CCC, ROHS, CE, CB, SIMKO, KEMA……

Brief Introduction:

-High cutting speed and low cost
-Small and smooth cutting seam, little transmulation.
-Current range from 40A to 200A for cutting different thickness of metal.

Specification:

cut welding machine, cutting welding machine, cut welder, air plasma cutter , dc air Plasma Cutter, inverter dc air plasma cutter
- Small size, light weight, and easy to carry (Mosfet)

- IGBT soft-switch technogy, more stable performance (IGBT)
- Adjustable output current to satisfy the cutting demands based on different kinds of material and thickness of working plate.
- Built-in over-heat protection, over-voltage protection, under voltage protection and lack of compressed air pressure protection.

Portable Air Plasma Cutter
Model	CUT-40	CUT-60
Type	MOSFET
Rated input voltage (V)	single phase AC220 ±15%	three phase AC380 ±15%
Rated frequency (Hz)	50/60
Rated input capacity (KVA)	6.6	7.9
Rated input current (A)	30	12
No-load voltage(V)	230	260
Output current (A)	20-40	20-60
Rated working voltage (V)	96	104
Duty cycle (%)	60	60
No-load loss (W)	100	100
Efficiency (%)	80	80
Power factor	0.73	0.73
Net weight (KG)	8.7	16.6
Gross weight (KG)	12	21
Dimension of machine (mm)	400×163×290	500×210×370
Dimension of packing (mm)	450×235×390	560×270×460
Method of arc start	contact	contact
Cutting thickness (mm)	steel: 0.3-16	steel: 1-25
Optimum thickness of work piece (mm)	steel: 0.3-8	steel: 1-15
Optimum thickness of work piece (mm)	aluminum/copper: 0.3-4	aluminum/copper: 1-7
including accessories: earth clamp×1pcs, cable joint×1pcs, grounding cable×3meters, pressure regulator×1pcs, gas hose×0.6meter, hose hoop×2pcs, cutting torch×1pcs

Accessories:

Packing:

Our Competive:

* BUY WITH CONFIDENCE.

* QUALITY MACHINES MANUFACTURED BY ANDELI.

* FULL SERVICE AND PARTS BACK UP.

* 24 MONTHS WARRANTY.

Our salesmen will reply your inquiry within 24 hours. Any order is welcome. If you like to be our agent in your country, we can give you any support on the technique & other aspects.

If you have any questions ,please contact with us....
