double-beam UV-Visible Spectrophotometer UV762 Wavelength Range190nm-1100nm
Features
1. Key parts adoptes imported components. New and distinctive optical system design ensures that main chine has superior optical performance and measuring property, low stray light, high-precision measurement and reliable stability.
2. Practical double-beam optical system is assorted with advanced monitoring system ensures that the instrument has high reliability and extremely low noise.
3. Distinctive deuterium lamp and tungsten lamp installation, auto-shift light source which can find favorable place design and working method automatically, guarantees convenient, accurate and safe for users.
4. It adopts large-screen LCD display, possessing of good human conversation interface.
5. Superior software design and programs make instrument has spectral data processing function: auto-scanning measuring spectrum, multi-wavelength measurement, dynamic measurement, 1-3 curve-fitting, 1-4 stages derivative spectrum, store, display print spectrum chart and analyze data.
6. It has the functions of good interface, powerful function, convenient store and output and saving on the basis of Windows platform.
Technical Parameters:
Type |
UV762 |
Wavelength Range |
190nm-1100nm |
Spectral Bandwidth |
2nm |
Wavelength Accuracy |
≤±0.3nm(auto-adjusting after opening) |
Wavelength Repeatability |
≤0.2nm |
Transmittance Accuracy |
±0.3%(T) |
Transmittance Repeatability |
0.2%(T) |
Transmittance Measuring Range |
0-200%T |
Absorbance Measuring Range |
-0.301-3.000A |
Stray Light |
≤0.15%(220nm, by NAI) |
Excursion |
≤0.002A/H(500nm) |
Noise |
100%line noise≤0.15%T; 0%line noise≤0.1%T |
Scanning Speed |
Fast, middle and slow |
