V1100 Desktop Single Beam Medical Visible Spectrophotometer 350-1020nm
This model is a simple single beam spectrometer. The wavelength is set manually from the dial on the front panel. Direct readout of transmission or absorption on the LED display. Measured values can be transferred to PC via the RS232 for further analysis. Low price and simple design make this model make this ideal tool for education or routine analysis.
Specifications:
Model |
V1100 |
VIS-722 |
VIS-722(N.S) |
Optical System |
Czerny-Turner (1200L/mm Grating) |
||
Wavelength |
350-1020nm |
320-1020nm |
320-1020nm |
Bandwidth |
6nm |
5nm |
4nm |
Wavelength Accuracy |
+/-2nm |
+/-2nm |
+/-2nm |
Wavelength Repeatability |
<=1nm |
<=1nm |
<=1nm |
Wavelength Set: |
Manually |
Manually |
Manually |
Work Mode |
T, A, C |
T, A, C |
T, A, C |
Photometric Accuracy |
+/-1%T |
+/-0.5%T |
+/-0.5%T |
Stability |
+/-0.004A/H @500nm |
+/-0.004A/H @500nm |
+/-0.003A/H @500nm |
Stray Light |
<=0.3%T |
<=0.3%T |
<=0.2%T |
Data Output |
RS232 |
RS232 |
RS232 |
Display Mode |
LED |
LED |
LED |
Detector: |
Silicon Photodiode |
Silicon Photodiode |
Silicon Photodiode |
Included Accessories
- 1 Main Instrument
- 1 Power Cable
- 4 x 10mm Glass Cuvettes
- 2 x 10mm Quartz Cuvettes
- 1 Cell Holder
- 1 Tungsten Lamp
- 1 Singal Cable
Optional Accessories
- 5mm-100mm Glass Cuvettes
- Tungsten Lamp
- 50mm-100mm Cell Holder
Overall Dimension & Weight
- Shipping Package Dimension: 520mm*450*320mm
- Gross Weight: 12kg
- Net Weight: 8kg
Applications
- Education in universities and colleges
- Environmental monitoring & control
- Food & Beverage production and quality control
- Agricultural monitoring
- Geology & metallurgy
- Gas & oil
