NOYAFA NF-868A Multifunction Troubleshooter Length Tester Phone Network LAN USB Coaxial Cable Troubleshooter Length Tester Red
US$ 50 - 75
/ Piece
5 Pieces(Min. Order)
- SHENZHEN
- T/T Money Gram Credit Card PayPal
You May Like
-
NOYAFA NF-868W Cable Length Tester Wire Tracker Cable Scanner Breakpoint Teste High Quality
-
Multi-function Cable Length Tester NOYAFA NF-868 Wire Tracker Cable ScannerBreakpoint Tester FOR RJ45/RJ11/BNC/USB
-
NOYAFA NF-300 Network Cable Test Hunting Wire Sorting and Cable Length Test 5E 6E Cable Coaxial RJ45 Anti-interference
-
Network Toolkit NOYAFA NF-1107 Incleded Wire Tracker Network Cable Tester Non-contact Voltage Detector Punch Tool Crimping Tool-
-
NEW Deviser DS2400T DVB-T/T2 Meter Terrestrial Signal Level Meter CATV METER(Many Stock)
-
Deviser DS2500 Series tv QAM Analyzer DS2500 QAM Analyzer Triple Play Maintenance Tool
Product Details
| Place of Origin | Guangdong, China | Brand Name | NOYAFA | |
| Model Number | NF-868A |
Product Description
NOYAFA NF-868A multifunction Troubleshooter Length Tester Phone Network LAN USB Coaxial Cable Troubleshooter Length Tester Red
Item specifics:
- Brand Name:NOYAFA
- Package:Yes
- Model Number: NF-868A
- Port: RJ11 RJ45 BNC USB
- Battery: 9V (not included)
- Color : Red
- Package: Carry bag+Color box
- Certificates: CE
Main Functions:
1. Measure length of RJ11/RJ45/BNC/USB Cable.
2. Test cable length up to 2000m and locate the short point accurately.
3. Check wiremap for RJ11/RJ45/BNC/USB Cable .
4. Test open, short , cross, reverse connection.
5. Check crosstalk on network cable to solve the potential problem of slow speed.
6. Functions of storage and memory.
7. Automatic delay power on-off and backlight function.
Accessories Included:
* Earphone x 1 set
* Battery x 2 sets
* Telephone line adapter x 1 set
* Network cable adapter x 1 set
* Cable clips x 1 set
| NF-868A Transmitter specifications | |
| LCD screen | 53x25mm |
| Tone frequency | 225Hz |
| The Max. distance of tracing cable | Electrified wire:3000m Non-electrified wire: 2000m |
| The Max. distance of cablemapping | 2500m |
| The Max. distance of cable length testing | 1000m |
| Trace cable coonected to switch | Anti-jamming |
| Tone mode | 2 Tones, adjustable |
| Compatible with connectors | RJ11,RJ45,BNC,USB |
| LED lights display | Wiremap, tone, tracing |
| Cable map indication | LCD (#1- #8) |
| Shielded indication | LCD (#9) |
| Voltage protection | AC 60V/DC 42V |
| Low battery display | LCD (6.5V) |
| Battery type | DC9.0VNEDA 1604/6F22 DC9V) x 1pc |
| Dimensions (LxWxD) | 185 x 80 x 32mm |
| NF-868A Remote unit specifications | |
| Compatible with connectors | RJ11,RJ45,BNC,USB |
| Dimensions (LxWxD) | 107 x 30 x 24mm |
