Help CenterDeviser DS6300C Network Certification Meter
Related Products
-
NEW Deviser AE500 CWDM Channel Analyzer Network AnalyzerUS$ 1 - 2MOQ: 1 Piece -
NEW Deviser AE100/AE120/AE160 Mini Optical Power MeterUS$ 1 - 2MOQ: 1 Piece
-
NEW Deviser NA7100 1.3GHz Vector Network AnalyzerUS$ 1 - 2MOQ: 1 Piece
-
NEW Deviser LS200 Series Light SourceUS$ 1 - 2MOQ: 1 Piece
-
Deviser NA7300 3.0GHz Vector Network AnalyzerUS$ 1 - 2MOQ: 1 Piece
Specifications
DVB-C Power Level : 30~110dBuV
Analog CATV Level : 20~120dBuV
QAM Source Range :5~65MHz
Description
DS6300C is mainly applied for the installation of data service of HFC Network, which is compatible with DOCSIS & Euro DOCSIS 1.1/2.0/3.0. Also it provides simple measurement of Analog TV, DVB-C and Spectrum.
Key Features
- 3.5 Inch TFT LCD
- USB storage and upgrade
- Toolbox - PC Management Software
Frequency | |
Range |
5 MHz ~ 1000 MHz |
Resolution |
10 kHz |
Accuracy |
±10 × 10-6 |
DVB-C | |
Power Level |
30 dBμV ~ 110 dBμV |
Resolution |
0.1 dB |
Accuracy |
±2.0 dB(C/N >20 dB) |
MER |
~38 dB |
MER Accuracy |
±2 dB |
BER |
1E-3 ~ 1E-9 |
Modulation Type |
64/128/256 QAM ITU-T J.83 Annex A/B/C |
Analog CATV | |
Level |
20 dBμV ~ 120 dBμV |
Resolution |
0.1 dB |
Accuracy |
±2.0 dB (C/N >20 dB) |
Functions |
Level, C/N, V/A, Tilt, Limit Test, Channel Scan, HUM |
Spectrum | |
Span |
Max. 995 MHz |
QAM Source | |
Range |
5 MHz ~ 65 MHz |
MER |
>38 dB |
Modulation Type |
QPSK; QAM (8/16/32/64); CW |
SR |
160/320/640/1280/ 2560/5120 KSym/s |
Level Output |
68 ~ 120 dBμV |
Others | |
Dimension |
247 mm × 130 mm × 67mm |
Weight |
1160 g |
Battery |
7.4 V / 4.4 AH Rechargeable Lithium-Ion |
Charge Time |
3 ~ 4 Hours |
Working Time |
>5 Hours |
